Honda Passport II (1997-2002) fuse 20 cond fan Wiring diagrams

A/C SWITCH A/C TRIPLE PRESSURE SWITCH (LEFT SIDE OF RADIATOR GRILLE) AIR CONDITIONING SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BRN WIRE CONDENSER FAN (BEHIND RIGHT SIDE OF RADIATOR GRILLE) CONDENSER FAN RELAY FUSE 20 COND FAN FUSE 7 A/C FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON PNK/WHT WIRE

A/C COMPRESSOR RELAY INTAKE ACTUATOR A/C DUAL PRESSURE SWITCH A/C TRIPLE PRESSURE SWITCH A/T ALARM, RELAY CONTROL UNIT SECURITY HORN ALTERNATOR ALTERNATOR HAZARD WARNING SWITCH BATTERY BLK WIRE BLOWER MOTOR BLU WIRE BRAKE SWITCH BRN WIRE C.B. 21 POWER WINDOW CEILING LIGHT CLOCK AUDIO UNIT CONDENSER FAN RELAY DASH FUSE BOX (BEHIND LEFT SIDE OF DASH) DATA LINK CONNECTOR DRIVER'S DOOR COURTESY LIGHT ECM OR PCM MAIN RELAY ELECTRONIC BRAKE CONTROL MODULE ENGINE CONTROL MODULE (ECM) OR POWERTRAIN CONTROL MODULE (PCM) FOG LIGHT RELAY HEADLIGHT RELAY FRONT PASSENGER'S DOOR COURTESY LIGHT CARGO AREA LIGHT ALARM, RELAY CONTROL UNIT FUEL PUMP RELAY FUSE 1 FUSE 1 HAZARD FUSE 3 ACG-S FUSE 13 ECM, BACKUP FUSE 15 FUSE 16 MAIN FUSE 17 ECM FUSE 18 ABS FUSE 19 FUSE 2 AUDIO FUSE 2 HORN FUSE 20 COND FAN FUSE 4 TAIL/ ILLUM FUSE 5 DOME LIGHT FUSE 5 BLOWER FUSE 6 BLOWER FUSE 6 STOP LIGHT FUSE 7 DOOR LOCK FUSE 7 A/C GAUGE ASSEMBLY GRN WIRE GRN/YEL WIRE HEATER-A/C RELAY HVAC CONTROL BEZEL A/C SWITCH J/C LEFT MAP LIGHT SWITCH RIGHT MAP LIGHT SWITCH LEFT REAR DOOR COURTESY LIGHT LT GRN WIRE LT GRN/WHT WIRE LX, EX M/T NCA WIRE NOT USED FUSE 10 FOG LIGHT ORG/ WIRE PNK PNK WIRE POWER WINDOW RELAY REAR DEFOGGER RELAY COIL REAR VIEW MIRROR (EX) RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT REAR DOOR COURTESY LIGHT SECURITY INDICATOR LIGHT (EX) KEY REMINDER SWITCH IGNITION SWITCH SOCKET STARTER RELAY STARTER SOLENOID TAILLIGHT RELAY THERMO SWITCH RELAY TO ACCESSORY POWER RELAY (DIAGRAM 2 OF 3) TO IGNITION SWITCH (DIAGRAM 2 OF 3) TO IGNTION SWITCH (DIAGRAM 2 OF 3) WHT WIRE YEL WIRE
