Honda Passport II (1997-2002) fuse 14 back-up Wiring diagram

12 LT ACCELERATION POSITION SENSOR ASSEMBLY (ON ACCEL PEDAL BRACKET) ACCELERATION SENSORS BLK WIRE BLK/BLU WIRE BLK/PPL WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/RED WIRE CLUTCH PEDAL POSITION SWITCH (ON CLUTCH PEDAL SUPPORT) CRUISE BRAKE THROTTLE VAL CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH RES/ACC CRUISE SET LIGHT DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) ENGINE OR POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT) EXTERIOR LIGHTS FUSE 11 METER FUSE 12 ENGINE FUSE 14 BACK-UP FUSE 6 STOP FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) FUSE 17 ECM GAUGE ASSEMBLY GRN WIRE GRN/WHT WIRE GRY WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUM INTERIOR LIGHTS LT GRN WIRE ON IND. ON SWITCH ORG/ WIRE ORG/BLU WIRE PCM MAIN RELAY (IN FUSE/ RELAY BOX) PNK WIRE PNK/YEL WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE RES/ACC IN IGN FEED SET/CST THROTTLE POSITION SENSOR 1 THROTTLE POSITION SENSOR 2 THROTTLE VALVE ASSEMBLY (ON THROTTLE BODY ASSEMBLY) THROTTLE VALVE MOTOR + TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANS) VEHICLE SPEED SENSOR (REAR OF TRANSMISSION) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
