Honda Passport II (1997-2002) engine control module or powertrain control module Wiring diagram
This page shows the only wiring diagram for the component.engine control module or powertrain control module, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine control module or powertrain control module (1 of 1)
ACCELERATION POSITION SENSOR ASSEMBLY SHIELD
ADC CONTROL UNIT
BATTERY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRAIDED WIRE
BRAKE FLUID LEVEL SWITCH
CONDENSER FAN
CONDENSER FAN RELAY
DATA LINK CONNECTOR
ECM OR PCM MAIN RELAY FUEL PUMP RELAY
EGR SOLENOID VALVE
ELECTRONIC BRAKE CONTROL MODULE
ENGINE CONTROL MODULE OR POWERTRAIN CONTROL MODULE
ENGINE HOOD SWITCH
FRONT AXLE ACTUATOR
FUSE/RELAY BOX
GAUGE ASSEMBLY
HEATER-A/C RELAY
INTAKE ACTUATOR RELAY
LEFT FOG LIGHT
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
PNK WIRE
REAR WASHER MOTOR
RIGHT FOG LIGHT
RIGHT FRONT PARKING/ TURN SIGNAL LIGHT
THROTTLE VALVE ASSEMBLY ASSEMBLY SHIELD
THROTTLE VALVE ASSEMBLY SHIELD
TRANSMISSION SPEED SENSOR SHIELD
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> ENGINE CONTROL MODULE OR POWERTRAIN CONTROL MODULE
