Honda Passport II (1997-2002) drvrs door open input Wiring diagram
This page shows the only wiring diagram for the component.drvrs door open input, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drvrs door open input (1 of 1)
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
ANTI-THEFT SYSTEM (IF EQUIPPED)
BATTERY
BEEPER
BLK WIRE
BLK/WHT WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 11 METER
DRIVER'S DOOR SWITCH
DRIVER'S SEAT BELT SWITCH
DRVRS BELT UNBLKD IN
DRVRS DOOR OPEN INPUT
ENGINE CONTROLS SYSTEM
FUSE 4 TAIL/ILLUM. LIGHT
FUSE 5 DOME LIGHT
FUSE 7 POWER DOOR LOCK
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
KEY IN IGN INPUT
KEY REMINDER SWITCH
LIGHTS ON INPUT
LT GRN/WHT WIRE
OFF
PARK
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SEAT BELT REMINDER LIGHT
SUPPLEMENTAL RESTRAINT SYSTEM
TAIL LIGHT RELAY (ON DASH FUSE BOX)
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> DRVRS DOOR OPEN INPUT
