Honda Passport II (1997-2002) air conditioning system Wiring diagram
This page shows the only wiring diagram for the component.air conditioning system, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioning system (1 of 1)
A/C SWITCH
A/C TRIPLE PRESSURE SWITCH (LEFT SIDE OF RADIATOR GRILLE)
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN WIRE
CONDENSER FAN (BEHIND RIGHT SIDE OF RADIATOR GRILLE)
CONDENSER FAN RELAY
FUSE 20 COND FAN
FUSE 7 A/C
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
PNK/WHT WIRE
Go to component -> Cooling fan circuit -> AIR CONDITIONING SYSTEM
