Honda Passport II (1997-2002) 2 1 3 1 2 3 ignition output gnd Wiring diagram
This page shows the only wiring diagram for the component.2 1 3 1 2 3 ignition output gnd, which is found in the car Honda Passport II (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 1 3 1 2 3 ignition output gnd (1 of 1)
2 1 3 1 2 3 IGNITION OUTPUT GND
4 1 (ISUZU) (HONDA)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION SWITCH
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
FLASHER UNIT (ABOVE LEFT KICK PANEL)
FUSE 1 HAZARD
FUSE 15 ELECT IG
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HAZARD OFF
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HOT AT ALL TIMES
HOT IN ON
LEFT
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
LEFT TURN INDICATOR LIGHT
OFF HAZARD
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT PARKING/ TURN SIGNAL LIGHT
RIGHT TURN INDICATOR LIGHT
TRAILER LIGHTING CONNECTOR (IN LEFT REAR CARGO COMPARTMENT, TAPED TO HARNESS)
TURN SIGNAL SWITCH
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> 2 1 3 1 2 3 IGNITION OUTPUT GND
