Rear washer/wiper circuit, late production for Honda Passport I (1993-1997)
Rear washer/wiper circuit, late production
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
DASH FUSE BOX
DIODE BOX E (LEFT SIDE OF TRUNK)
GRN/RED WIRE
GRY WIRE
HATCH OPEN SWITCH (CENTER OF TAILGATE)
HOT IN ON OR START
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
OFF
ORG/ WIRE
ORG/BLU WIRE
PARK
REAR WASHER MOTOR (ON WASHER FLUID RESERVOIR)
REAR WASHER SWITCH
REAR WIPER CB-16
REAR WIPER CONTROLLER (LEFT SIDE OF TRUNK)
REAR WIPER MOTOR (INSIDE RIGHT SIDE OF TAILGATE)
REAR WIPER RELAY (LEFT SIDE OF TRUNK)
REAR WIPER SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RUN WIRE
TRUNK, TAILGATE, FUEL DOOR SYSTEM
WASH
WHT WIRE
WIPE
YEL/BLU WIRE
YEL/RED WIRE
