Starting circuit, a/t early production for Honda Passport I (1993-1997)
Starting circuit, a/t early production
1995 VFTC
AUTOMATIC TRANSMISSION MODE SWITCH (ON LEFT SIDE OF TRANSMISSON)
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DASH FUSE BOX
DIODE BOX A
DIODE BOX B
ENGINE CONTROL MODULE (ECM) (AT LEFT KICK PANEL) P/N INPUT
FUSE 11
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
HD IN PL IN
IGNITION SWITCH
LOCK
MAIN FUSE 1
OFF
ORG/ WIRE
RED WIRE
STARTER
STARTER MOTOR
STARTER RELAY
STARTER SOLENOID
TRUNK/TAILGATE/ FUEL DOORS SYSTEM
WHT WIRE
WHT/BLU WIRE
YEL WIRE
