Starting circuit, a/t late production for Honda Passport I (1993-1997)
Starting circuit, a/t late production
1995 VFTC
AUTOMATIC TRANSMISSION MODE SWITCH (ON LEFT SIDE OF TRANSMISSON)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/PNK WIRE
BRN WIRE
DASH FUSE BOX
DIODE BOX A
DIODE BOX B
ENGINE CONTROL MODULE (ECM) (BELOW CENTER OF DASH) P/N INPUT
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
HD IN PL IN
IGNITION SWITCH
LOCK
MAIN FUSE EB-16
OFF
PNK WIRE
PPL 4
RED WIRE
STARTER
STARTER FUSE CB-1
STARTER RELAY
STARTER SOLENOID
TRUNK,TAILGATE, FUEL DOORS SYSTEM (REAR WIPER MOTOR SWITCH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
