Shift interlock circuit, late production for Honda Passport I (1993-1997)
Shift interlock circuit, late production
ANTI-LOCK BRAKES, CRUISE CONTROL SYSTEMS
BATTERY
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE SW IN IGNITION GROUND
BRAKE SWITCH (LEFT SIDE OF DASH BOARD)
DASH FUSE BOX
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES STOP CB-13
HOT IN ON OR START
METER CB-7
PARK POSITION SWITCH (AT AUTOMATIC TRANSMIS- SION SHIFT LEVER)
RED WIRE
SHIFT LOCK CONTROLLER (AT AUTOMATIC TRANSMISSION SHIFT LEVER)
SHIFT LOCK SOLENOID (AT AUTOMATIC TRANSMIS- SION SHIFT LEVER)
SOL CTRL SOL CTRL PARK INPUT REF SIGNAL
YEL WIRE
