Shift interlock circuit, early production for Honda Passport I (1993-1997)
Shift interlock circuit, early production
BATTERY
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE INPUT
BRAKE LIGHT SWITCH
CHARGE SIG
DASH FUSE BOX (LEFT SIDE OF I/P)
FUSE 2
FUSE 7
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON FUSE/ RELAY BOX (RIGHT SIDE FUSE 6
HOT IN ON OR START
IGNITION
OF ENGINE COMPARTMENT)
PARK INPUT
PARKING SWITCH (BELOW SHIFT LEVER COVER)
RED WIRE
REF SIGNAL
SAFETY LOCK CONTROL UNIT (AT A/T LEVER)
SHIFT LOCK SOLENOID
SOLENOID CONTROL
WHT WIRE
WHT/RED WIRE
YEL WIRE
