Power window circuit, early production for Honda Passport I (1993-1997)
Power window circuit, early production
AUTO DOWN CONTROLLER
AUTO DOWN DOWN
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
CIRCUIT BREAKER
DASH FUSE BOX
DOWN
DOWN UP
FUSE 7
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT POWER WINDOW SWITCH
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LOCK SWITCH
POWER WINDOW RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
UP OFF
WHT WIRE
YEL WIRE
