Power door lock circuit, early production for Honda Passport I (1993-1997)
Power door lock circuit, early production
AUTOMATIC DOOR LOCK CONTROL RELAY (RIGHT SIDE KICK PANEL)
AUTOMATIC DOOR LOCK LOCK SWITCH (INSIDE REAR OF LEFT FRONT DOOR)
BLK WIRE
BLK/BLU WIRE
GRN WIRE
HOT AT ALL TIMES DASH FUSE BOX FUSE 4
LEFT REAR AUTOMATIC DOOR LOCK MOTOR
LOCK
RED WIRE
RIGHT FRONT AUTOMATIC DOOR LOCK MOTOR
RIGHT REAR AUTOMATIC DOOR LOCK MOTOR
UNLOCK
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
