Headlight circuit, early production for Honda Passport I (1993-1997)
Headlight circuit, early production
2.6L 3.2L
3.2L 2.6L
BLK WIRE
BLU WIRE
DIMMER/ PASSING SWITCH (COMBINATION SWITCH)
DIMMING SWITCH
FLASH TO PASS SWITCH
FUSE 10
FUSE 9
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN/RED WIRE
HEAD
HEADLIGHT RELAY
HIGH BEAM INDICATOR
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LIGHT
LIGHT SWITCH
MAIN FUSE 2
OFF
PARK OFF
PARK OFF PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLAMP
