Ground distribution circuit, early production for Honda Passport I (1993-1997)
Ground distribution circuit, early production (1 of 4)
16 3 (A/T)
3.2L 2.6L
A/T ONLY
AUTOMATIC TRANSMISSION MODE SWITCH
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BRAIDED WIRE
DATA LINK CONNECTOR
ELECTRONIC IGNITION SYSTEM
ENGINE
ENGINE CONTROL MODULE
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR SHIELDS
LEFT FRONT COMBINATION LIGHT
LEFT FRONT SIDE MARKER LIGHT
RED WIRE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT SIDE MARKER LIGHT
TRANSMISSION CONTROL MODULE SHIELD
VALVE COVER)
VEHICLE SPEED SENSOR
WHT WIRE
WINDSHIELD WASHER MOTOR
Ground distribution circuit, early production (2 of 4)
2.6L
3.2L
A/T
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BRAIDED WIRE
CHARGE RELAY
CONDENSER FAN
CONDENSER FAN RELAY
CRANK POSITION SENSOR
CRANK POSITION SENSOR SHIELD
CRUISE CONTROL PUMP/ACTUATOR
DATA LINK CONNECTOR
DIAGNOSTIC TEST TERMINAL
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE RELAY
FUEL PUMP RELAY
FUSE/RELAY BOX
GRY WIRE
HEATER-A/C RELAY
INDICATOR SWITCH
NOISE CONDENSER
REAR WHEEL ANTI-LOCK BRAKE VALVE
RED/BLU WIRE
STARTER RELAY (M/T)
UPSHIFT RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY OR CONNECTOR PLUG
Ground distribution circuit, early production (3 of 4)
2.6L
9 14 (3.2L)
A/T
AIR REGULATOR
AUTOMATIC DOOR LOCK CONTROL RELAY
AUTOMATIC DOOR LOCK SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
CIGARETTE LIGHTER
COMBINATION SWITCH
CRUISE CONTROL UNIT
DRIVER'S POWER MIRROR
EX+
FAST IDLE SOLENOID VALVE
FLASHER UNIT
GRN WIRE
HEATER-A/C CONTROL PANEL
ILLUMINATION CONTROLLER
INSTRUMENT CLUSTER
KICK DOWN SWITCH
LEFT FRONT POWER WINDOW SWITCH
LIGHT SWITCH
PASSENGER'S POWER MIRROR
POWER/ WINTER SWITCH
RADIO
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
REAR WIPER/WASHER SWITCH
SAFETY LOCK CONTROL UNIT
TRANSMISSION CONTROL MODULE
TRANSMISSON CONTROL MODULE DIAGNOSTIC CONNECTOR
WARNING BUZZER CONTROL UNIT
Ground distribution circuit, early production (4 of 4)
3.2L 2.6L
BLK WIRE
BRAIDED WIRE
DRIVER'S SEAT BELT SWITCH
EX+
FUEL PUMP
FUEL TANK UNIT
GRN/RED WIRE
HIGH MOUNTED STOP LIGHT
LEFT TAILLIGHT ASSEMBLY
LICENSE LIGHT
MIRROR DEFOGGER SWITCH
POWER MIRROR SWITCH
REAR DEFOGGER SWITCH
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER
REAR WIPER CONTROLLER
REAR WIPER MOTOR
RIGHT TAILLIGHT ASSEMBLY
TRAILER CONNECTOR
