Honda Passport I (1993-1997) warning light control Wiring diagrams
This page contains all the electrical diagrams for the component. warning light control, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
warning light control wiring diagram (1 of 2)
8 9 (2.6L) (3.2L)
BLK WIRE
BLK/GRN WIRE
DOOR SWITCH INPUT
DRIVER'S SEAT BELT SWITCH
FUSE 1
FUSE 3
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND
HEAD OFF
HOT AT ALL TIMES
HOT IN ON OR START DASH FUSE BOX (LEFT SIDE OF I/P) FUSE 7
IGNITION INPUT
KEY IN IGNITION INPUT
KEY REMIND SWITCH
LEFT FRONT DOOR SWITCH
LIGHT SWITCH
LIGHTS ON INPUT
PARK
PPL
RED WIRE
SEAT BELT UNBUCKLE INPUT
WARNING BUZZER CONTROL UNIT (RIGHT SIDE OF I/P)
WARNING LIGHT CONTROL
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits, early production -> WARNING LIGHT CONTROL
warning light control wiring diagram (2 of 2)
10 4 (2.6L) (3.2L)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
DOOR SWITCH INPUT
DRIVER'S SEAT BELT SWITCH
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND
HEAD
HOT AT ALL TIMES
HOT IN ON OR START DASH FUSE BOX CB-7 METER
IGNITION INPUT
KEY IN IGNITION INPUT
KEY REMINDER SWITCH
LEFT FRONT DOOR SWITCH
LIGHT SWITCH
LIGHTS ON INPUT
OFF
PARK
PNK WIRE
RED WIRE
RED/BLK WIRE
ROOM CB-9
SEAT BELT, KEY AND LIGHT REMINDER BUZZER (BELOW LEFT SIDE OF DASH)
SUPPLE- MENTAL RESTRAINT SYSTEM
TAIL LIGHT RELAY (LEFT KICK PANEL)
TAIL-ILLUMI CB-5
WARNING LIGHT CONTROL
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits, late production -> WARNING LIGHT CONTROL
