Honda Passport I (1993-1997) up/ right switch 2 Wiring diagram
This page shows the only wiring diagram for the component.up/ right switch 2, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up/ right switch 2 (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
DASH FUSE BOX
DOWN RIGHT
DOWN/ LEFT
DRIVER'S POWER MIRROR
FUSE 12
GRN/RED WIRE
HOT IN ACC OR ON
LEFT RIGHT
LEFT/RIGHT
MIRROR SELECTOR SWITCH
POWER MIRROR SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT POWER MIRROR UP/DOWN
SWITCH 1
SWITCH 3
SWITCH 4
UP LEFT
UP/ RIGHT
UP/ RIGHT SWITCH 2
UP/DOWN
WHT BRN WIRE
WHT WIRE
Go to component -> Power mirror circuit, early production -> UP/ RIGHT SWITCH 2
