Honda Passport I (1993-1997) transmisson control module diagnostic connector wiring diagram
This page shows the only wiring diagram for the component.transmisson control module diagnostic connector, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
transmisson control module diagnostic connector wiring diagram (1 of 1)
2.6L
9 14 (3.2L)
A/T
AIR REGULATOR
AUTOMATIC DOOR LOCK CONTROL RELAY
AUTOMATIC DOOR LOCK SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
CIGARETTE LIGHTER
COMBINATION SWITCH
CRUISE CONTROL UNIT
DRIVER'S POWER MIRROR
EX+
FAST IDLE SOLENOID VALVE
FLASHER UNIT
GRN WIRE
HEATER-A/C CONTROL PANEL
ILLUMINATION CONTROLLER
INSTRUMENT CLUSTER
KICK DOWN SWITCH
LEFT FRONT POWER WINDOW SWITCH
LIGHT SWITCH
PASSENGER'S POWER MIRROR
POWER/ WINTER SWITCH
RADIO
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
REAR WIPER/WASHER SWITCH
SAFETY LOCK CONTROL UNIT
TRANSMISSION CONTROL MODULE
TRANSMISSON CONTROL MODULE DIAGNOSTIC CONNECTOR
WARNING BUZZER CONTROL UNIT
Go to component -> Ground distribution circuit, early production (3 of 4) -> TRANSMISSON CONTROL MODULE DIAGNOSTIC CONNECTOR
