Honda Passport I (1993-1997) transmission switch 3-4 neutral switch Wiring diagram
This page shows the only wiring diagram for the component.transmission switch 3-4 neutral switch, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission switch 3-4 neutral switch (1 of 1)
2.6L
3.2L
3.2L 2.6L
A/T
BACK UP LIGHTS SWITCH BACK UP LIGHTS SWITCH
BLK/GRN OR BLK/WHT WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE LIGHT SWITCH
CLUTCH
CRUISE CONTROL SWITCH
DASH FUSE BOX
DIODE BOX B
ELECTRONIC IGNITION SYSTEM IGNITION COIL
FROM FUSES 6&7 (DASH FUSE BOX) (DIAGRAM 4 OF 5)
FROM IGNITION SWITCH (DIAGRAM 1 OF 5 (2.6L)) (DIAGRAM 2 OF 5 (3.2L))
FUSE 11
FUSE 8
FUSE 9
FUSE/ RELAY BOX
GENERATOR
M/T
NCA WIRE
POWERTRAIN CONTROL MODULE
POWERTRAIN CONTROL MODULE RELAY
RADIO NOISE SUPPRESSOR
RED WIRE
RED/BLK WIRE
STARTER RELAY
SWITCH
TRANSMISSION SWITCH 1-2
TRANSMISSION SWITCH 3-4 NEUTRAL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Power distribution circuit, early production (5 of 5) -> TRANSMISSION SWITCH 3-4 NEUTRAL SWITCH
