Honda Passport I (1993-1997) tailgate opener switch Wiring diagrams
This page contains all the electrical diagrams for the component. tailgate opener switch, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tailgate opener switch (1 of 3)
3.2L 2.6L
A/T
ASHTRAY ILLUMINATION
BLK WIRE
CIGARETTE LIGHTER ILLUMINATION
DASH FUSE BOX (LEFT SIDE OF I/P)
FUSE 1
GRN WIRE
GRN/RED WIRE
GROUND
HEAD OFF PARK
HEATER-A/C CONTROL PANEL
HOT AT ALL TIMES
ILLUMINATION
ILLUMINATION CONTROL
ILLUMINATION CONTROLLER (BEHIND LEFT SIDE OF I/P)
INSTRUMENT CLUSTER
LIGHT SWITCH
LX, EX ONLY
MIRROR DEFOGGER SWITCH
POWER
POWER MIRROR SWITCH
POWER/ WINTER SWITCH
RADIO
REAR DEFOGGER SWITCH
RED WIRE
RED/GRN WIRE
SHIFT LEVER ILLUMINATION
TAILGATE OPENER SWITCH
VIO WIRE
WASHER BUTTON ILLUMI- NATION
WHT WIRE
WINDSHIELD WIPER/ WASHER SWITCH
Go to component -> Interior light circuit, early production (2 of 2) -> TAILGATE OPENER SWITCH
Wiring diagram tailgate opener switch (2 of 3)
1994 VFTC
2.6L
2.6L 3.2L
3.2L
A/T ONLY
A/T ONLY M/T ONLY
AUTOMATIC DOOR LOCK CONTROL RELAY
BLK WIRE
BLK/BLU WIRE
BRAKE LIGHT SWITCH
CIRCUIT BREAKER
DASH FUSE BOX
EX ONLY
FROM MAIN FUSE 1 (FUSE/RELAY BOX) (DIAGRAM 2 OF 5)
FUSE 1
FUSE 2
FUSE 3
FUSE 4
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
KEY REMIND SWITCH POWERTRAIN CONTROL MODULE
LEFT FRONT DOOR COURTESY LIGHT RIGHT FRONT DOOR COURTESY LIGHT
LEFT REAR DOOR COURTESY LIGHT
LIGHT SWITCH
LUGGAGE ROOM LIGHT
LX,EX ONLY
POWER WINDOW RELAY
PPL
RADIO
REAR DEFOGGER RELAY
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER BRAKE LIGHT SWITCH
RED WIRE
RED/WHT WIRE
RIGHT REAR DOOR COURTESY LIGHT
SAFETY LOCK CONTROL UNIT
SPOT LIGHT ASSEMBLY DOME LIGHT
TAILGATE OPENER SWITCH
TRANSMISSION CONTROL MODULE
Go to component -> Power distribution circuit, early production (3 of 5) -> TAILGATE OPENER SWITCH
Wiring diagram tailgate opener switch (3 of 3)
A/T
A/T MODE SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLK/ BLU WIRE
BLK/BLU WIRE
BLU/ BLK WIRE
BLU/BLK WIRE
DASH FUSE BOX
DIODE BOX A (FUSE/ RELAY BOX)
DIODE BOX C (BEHIND LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (NEXT TO LEFT KICK PANEL)
FUSE 4
GRN RED/ WIRE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
INT OFF WIPE
M/T
ORG/ WIRE
PARK
PARKING BRAKE SWITCH (UNDER CENTER CONSOLE)
PNK/ BLK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
REAR WIPER MOTOR ON SWITCH (RIGHT SIDE OF TAILGATE)
REAR/WIPER WASHER SWITCH (BEHIND LEFT SIDE OF DASH)
RED WIRE
RED/BLU WIRE
RUN WIRE
STARTING/ CHARGING SYSTEM
TAILGATE GLASS OPENER ACTUATOR (CENTER OF TAILGATE)
TAILGATE OPENER SWITCH
YEL WIRE
Go to component -> Tailgate release circuit, early production -> TAILGATE OPENER SWITCH
