Honda Passport I (1993-1997) right front combination light park Wiring diagram
This page shows the only wiring diagram for the component.right front combination light park, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front combination light park (1 of 1)
BLK WIRE
DASH FUSE BOX (LEFT SIDE OF I/P)
FUSE 1
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HEAD
HEAD OFF OFF PARK PARK
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LEFT FRONT COMBINATION LIGHT TURN TURN PARK
LEFT FRONT SIDE MARKER LIGHT
LICENSE LIGHT
LIGHT SWITCH
PPL
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT COMBINATION LIGHT PARK
RIGHT FRONT SIDE MARKER LIGHT
Go to component -> Exterior lamps circuit, early production (1 of 2) -> RIGHT FRONT COMBINATION LIGHT PARK
