Honda Passport I (1993-1997) rear defogger switch Wiring diagrams

This page contains all the electrical diagrams for the component. rear defogger switch, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

rear defogger switch wiring diagram (1 of 7)

BLK WIRE BLU WIRE BRN WIRE DASH FUSE BOX (LEFT SIDE OF I/P) FUSE 4 FUSE 7 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUMI- NATION LS MODELS ON INDICATOR ON OFF POWER WINDOW RELAY REAR DEFOGGER REAR DEFOGGER RELAY REAR DEFOGGER SWITCH RED WIRE YEL WIRE

Go to component -> Defogger circuit, early production -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (2 of 7)

BLK WIRE BLK/RED WIRE DASH FUSE BOX (LEFT SIDE OF I/P) GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START METER CB FUSE 7 OFF ON INDICATOR REAR DEFOGGER REAR DEFOGGER RELAY (LEFT KICK PANEL) REAR DEFOGGER SWITCH RED WIRE RR DEF NO. 1 CB FUSE 17 RR DEF NO. 2 CB FUSE 18 SWITCH LIGHT YEL WIRE YEL/GRN WIRE

Go to component -> Defogger circuit, late production -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (3 of 7)

2.6L 9 14 (3.2L) A/T AIR REGULATOR AUTOMATIC DOOR LOCK CONTROL RELAY AUTOMATIC DOOR LOCK SWITCH BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE CIGARETTE LIGHTER COMBINATION SWITCH CRUISE CONTROL UNIT DRIVER'S POWER MIRROR EX+ FAST IDLE SOLENOID VALVE FLASHER UNIT GRN WIRE HEATER-A/C CONTROL PANEL ILLUMINATION CONTROLLER INSTRUMENT CLUSTER KICK DOWN SWITCH LEFT FRONT POWER WINDOW SWITCH LIGHT SWITCH PASSENGER'S POWER MIRROR POWER/ WINTER SWITCH RADIO REAR DEFOGGER RELAY REAR DEFOGGER SWITCH REAR WIPER/WASHER SWITCH SAFETY LOCK CONTROL UNIT TRANSMISSION CONTROL MODULE TRANSMISSON CONTROL MODULE DIAGNOSTIC CONNECTOR WARNING BUZZER CONTROL UNIT

Go to component -> Ground distribution circuit, early production (3 of 4) -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (4 of 7)

3.2L 2.6L BLK WIRE BRAIDED WIRE DRIVER'S SEAT BELT SWITCH EX+ FUEL PUMP FUEL TANK UNIT GRN/RED WIRE HIGH MOUNTED STOP LIGHT LEFT TAILLIGHT ASSEMBLY LICENSE LIGHT MIRROR DEFOGGER SWITCH POWER MIRROR SWITCH REAR DEFOGGER SWITCH REAR WHEEL ANTI-LOCK BRAKE CONTROLLER REAR WIPER CONTROLLER REAR WIPER MOTOR RIGHT TAILLIGHT ASSEMBLY TRAILER CONNECTOR

Go to component -> Ground distribution circuit, early production (4 of 4) -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (5 of 7)

15 16 (3.2L) 3.2L 3.2L M/T A/T BACK UP PARK/ STOP BLK WIRE BLK/RED WIRE CIGARETTE LIGHT COMBINATION SWITCH CRUISE CONTROL UNIT RIGHT POWER MIRROR DRIVER'S SEAT BELT SWITCH ELECTRONIC BRAKE CONTROL MODULE FAN CONTROL SWITCH FLASHER UNIT GAUGE ASSEMBLY GRN/RED WIRE HIGH MOUNT BRAKE LIGHT ILLUMINATION CONTROLLER KICKDOWN SWITCH LEFT FRONT DOOR POWER WINDOW, LOCK SWITCH LEFT POWER MIRROR LEFT REAR POWER WINDOW SWITCH LEFT TAILLIGHT PARK/ STOP BACK UP TURN LICENSE LIGHT MIRROR CONTROL SWITCH MIRROR DEFOGGER SWITCH POWER WINDOW RELAY POWER/WINTER SWITCH SHIFT LOCK CONTROLLER RADIO REAR DEFOGGER SWITCH REAR WASHER SWITCH REAR WIPER CONTROLLER REAR WIPER MOTOR REAR WIPER SWITCH RIGHT FRONT DOOR POWER WINDOW, LOCK SWITCH RIGHT REAR POWER WINDOW SWITCH REAR DEFOGGER RIGHT TAILLIGHT SEAT BELT, KEY, LIGHT REMINDER BUZZER SRS DATA LINK CONNECTOR TURN UPSHIFT RELAY WHT WIRE

Go to component -> Ground distribution circuit, late production (3 of 3) -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (6 of 7)

3.2L 2.6L A/T ASHTRAY ILLUMINATION BLK WIRE CIGARETTE LIGHTER ILLUMINATION DASH FUSE BOX (LEFT SIDE OF I/P) FUSE 1 GRN WIRE GRN/RED WIRE GROUND HEAD OFF PARK HEATER-A/C CONTROL PANEL HOT AT ALL TIMES ILLUMINATION ILLUMINATION CONTROL ILLUMINATION CONTROLLER (BEHIND LEFT SIDE OF I/P) INSTRUMENT CLUSTER LIGHT SWITCH LX, EX ONLY MIRROR DEFOGGER SWITCH POWER POWER MIRROR SWITCH POWER/ WINTER SWITCH RADIO REAR DEFOGGER SWITCH RED WIRE RED/GRN WIRE SHIFT LEVER ILLUMINATION TAILGATE OPENER SWITCH VIO WIRE WASHER BUTTON ILLUMI- NATION WHT WIRE WINDSHIELD WIPER/ WASHER SWITCH

Go to component -> Interior light circuit, early production (2 of 2) -> REAR DEFOGGER SWITCH

rear defogger switch wiring diagram (7 of 7)

3.2L 3.2L 2.6L ASHTRAY LIGHT BLK WIRE CIGARETTE LIGHTER LIGHT COMBINATION SWTICH CRUISE CONTROL MAIN SWITCH DASH FUSE BOX (LEFT SIDE OF I/P) GAUGE ASSEMBLY (3 BULBS- 3.2L) (2 BULBS- 2.6L) GRN WIRE GRN/RED WIRE GROUND HATCH RELEASE SWITCH HAZARD WARNING SWITCH HEAD OFF PARK HEADLIGHT SWITCH HEATER CONTROL PANEL LIGHT HOT AT ALL TIMES ILLUMINATION CONTROL ILLUMINATION CONTROLLER (BEHIND LEFT SIDE OF I/P) POWER MIRROR CONTROL SWITCH MIRROR DEFOGGER SWITCH POWER/ WINTER SWITCH RADIO REAR DEFOGGER SWITCH REAR WASHER SWITCH REAR WIPER SWITCH RED WIRE RED/BLK WIRE SHIFT LEVER LIGHT TAIL ILLUM TAILLIGHT RELAY (LEFT KICK PANEL) WHT WIRE YEL WIRE

Go to component -> Interior light circuit, late production (2 of 2) -> REAR DEFOGGER SWITCH
