Honda Passport I (1993-1997) press diff brake switch Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 3 I-15 1 I-15 10 I-15 10 I-16 12 I-16 STARTING/ CHARGING SYSTEM (GENERATOR) 2 I-15 I-16 4 I-15 4 I-16 6 I-15 5 I-15 7 I-16 8 I-16 9 I-15 9 I-16 A-27 A-28 BLK WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/GRN WIRE BRAKE WARN LIGHT CTRL BRAKE WARNING LIGHT CHARGE WARNING LIGHT CHECK ENGINE MALFUNCTION INDICATOR LAMP COMBINATION VALVE PRESSURE DIFFERENTIAL SWITCH (IN BRAKE FLUID VALVE) DASH FUSE BOX DIODE BOX D (BEHIND LEFT SIDE OF I/P) ENGINE CONTROL MODULE (ECM) (LEFT KICK PANEL) ENGINE CONTROLS SYSTEM (DIODE BOX A) ENGINE COOLANT TEMPERATURE GAUGE EXTERIOR LIGHTS SYSTEM (COMBINATION SWITCH) FUEL GAUGE FUEL TANK UNIT (RIGHT FRONT OF FUEL TANK) FUSE 7 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM HI BEAM INDICATOR LIGHT HOT IN ON OR START I-15 I-16 ILLUMINATION INDICATOR CANCEL SWITCH INDICATOR LIGHT INSTRUMENT CLUSTER INTERNAL VOLTAGE REGULATOR LEFT TURN INDICATOR LIGHT LOW FUEL WARNING LIGHT LT BLU WIRE LT GRN/BLK WIRE NCA WIRE OIL PRESSURE SWITCH (LOWER FRONT OF ENGINE) OIL PRESSURE WARNING LIGHT ORG/BLK WIRE PARKING BRAKE SWITCH (ON PARKING BRAKE LEVER) PNK WIRE PNK/BLK WIRE PRESS DIFF BRAKE SWITCH REAR WHEEL ANTI-LOCK BRAKE CONTROLLER (BELOW RIGHT FRONT SEAT) RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT TURN INDICATOR LIGHT RR ANTI-LOCK BRAKE WARNING LIGHT RWAL INDIC LIGHT CTRL SEATBELT WARNING LIGHT VEHICLE SPEED SENSOR WARNING SYSTEM (WARNING BUZZER CONTROL UNIT) WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/PPL WIRE YEL/RED WIRE
