Honda Passport I (1993-1997) passing switch wiring diagram
This page shows the only wiring diagram for the component.passing switch, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passing switch wiring diagram (1 of 1)
2.6L
4 14 (3.2L) GAUGE ASSEMBLY HIGH BEAM INDICATOR
BLK WIRE
COMBINATION SWITCH
DIMMING SWITCH
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
HEADLIGHT RELAY
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT HEADLAMP
LH H/LAMP FUSE EB 8
LIGHT
OFF HEAD
PARK
PASSING SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH H/LAMP FUSE EB 9
RIGHT HEADLAMP
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Headlight circuit, late production -> PASSING SWITCH
