Honda Passport I (1993-1997) on indicator Wiring diagrams
This page contains all the electrical diagrams for the component. on indicator, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
on indicator wiring diagram (1 of 4)
Go to component -> Defogger circuit, early production -> ON INDICATOR
on indicator wiring diagram (2 of 4)
BLK WIRE
BLK/RED WIRE
DASH FUSE BOX (LEFT SIDE OF I/P)
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
METER CB FUSE 7
OFF
ON INDICATOR
REAR DEFOGGER
REAR DEFOGGER RELAY (LEFT KICK PANEL)
REAR DEFOGGER SWITCH
RED WIRE
RR DEF NO. 1 CB FUSE 17
RR DEF NO. 2 CB FUSE 18
SWITCH LIGHT
YEL WIRE
YEL/GRN WIRE
Go to component -> Defogger circuit, late production -> ON INDICATOR
on indicator wiring diagram (3 of 4)
Go to component -> Heated mirrors circuit, early production -> ON INDICATOR
on indicator wiring diagram (4 of 4)
Go to component -> Heated mirrors circuit, late production -> ON INDICATOR
