Honda Passport I (1993-1997) mirror control switch mirror defogger switch Wiring diagram
This page shows the only wiring diagram for the component.mirror control switch mirror defogger switch, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror control switch mirror defogger switch (1 of 1)
15 16 (3.2L)
3.2L
3.2L M/T
A/T
BACK UP PARK/ STOP
BLK WIRE
BLK/RED WIRE
CIGARETTE LIGHT
COMBINATION SWITCH
CRUISE CONTROL UNIT RIGHT POWER MIRROR
DRIVER'S SEAT BELT SWITCH
ELECTRONIC BRAKE CONTROL MODULE
FAN CONTROL SWITCH
FLASHER UNIT
GAUGE ASSEMBLY
GRN/RED WIRE
HIGH MOUNT BRAKE LIGHT
ILLUMINATION CONTROLLER
KICKDOWN SWITCH
LEFT FRONT DOOR POWER WINDOW, LOCK SWITCH
LEFT POWER MIRROR
LEFT REAR POWER WINDOW SWITCH
LEFT TAILLIGHT PARK/ STOP BACK UP TURN
LICENSE LIGHT
MIRROR CONTROL SWITCH MIRROR DEFOGGER SWITCH
POWER WINDOW RELAY
POWER/WINTER SWITCH SHIFT LOCK CONTROLLER
RADIO
REAR DEFOGGER SWITCH
REAR WASHER SWITCH
REAR WIPER CONTROLLER REAR WIPER MOTOR
REAR WIPER SWITCH
RIGHT FRONT DOOR POWER WINDOW, LOCK SWITCH
RIGHT REAR POWER WINDOW SWITCH REAR DEFOGGER
RIGHT TAILLIGHT
SEAT BELT, KEY, LIGHT REMINDER BUZZER
SRS DATA LINK CONNECTOR
TURN
UPSHIFT RELAY
WHT WIRE
Go to component -> Ground distribution circuit, late production (3 of 3) -> MIRROR CONTROL SWITCH MIRROR DEFOGGER SWITCH
