Honda Passport I (1993-1997) left taillight assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left taillight assembly, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left taillight assembly (1 of 2)
2.6L
3.2L
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/WHT WIRE
BRAKE LIGHT SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CRUISE CONTROL SYSTEM
DASH FUSE BOX (LEFT SIDE OF I/P)
FLASHER UNIT (BEHIND LEFT SIDE OF I/P, ABOVE KICK PANEL)
FUSE 2
FUSE 3
FUSE 7
FUSE/ RELAY BOX
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HAZARD
HIGH MOUNT STOP LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LEFT TAILLIGHT ASSEMBLY
LEFT TURN
OFF
OFF OFF
OUTPUT
PARK
POWER
RED WIRE
RIGHT TAILLIGHT ASSEMBLY
RIGHT TURN
STOP PARK
STOP TURN SIGNAL LIGHT
TRAILER CONNECTOR (BENEATH VEHICLE, BEHIND RIGHT REAR CORNER OF FUEL TANK)
TURN
TURN SIGNAL INDIC. LH RH
TURN SIGNAL LIGHT
TURN SIGNAL/ HAZARD WARNING SWITCH (COMBINATION SWITCH)
YEL WIRE
Go to component -> Exterior lamps circuit, early production (2 of 2) -> LEFT TAILLIGHT ASSEMBLY
Wiring diagram left taillight assembly (2 of 2)
3.2L 2.6L
BLK WIRE
BRAIDED WIRE
DRIVER'S SEAT BELT SWITCH
EX+
FUEL PUMP
FUEL TANK UNIT
GRN/RED WIRE
HIGH MOUNTED STOP LIGHT
LEFT TAILLIGHT ASSEMBLY
LICENSE LIGHT
MIRROR DEFOGGER SWITCH
POWER MIRROR SWITCH
REAR DEFOGGER SWITCH
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER
REAR WIPER CONTROLLER
REAR WIPER MOTOR
RIGHT TAILLIGHT ASSEMBLY
TRAILER CONNECTOR
Go to component -> Ground distribution circuit, early production (4 of 4) -> LEFT TAILLIGHT ASSEMBLY
