Honda Passport I (1993-1997) left right Wiring diagrams
This page contains all the electrical diagrams for the component. left right, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left right wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BLU/RED WIRE
DASH FUSE BOX
DOWN RIGHT
DOWN/ LEFT
DRIVER'S POWER MIRROR
FUSE 12
GRN/RED WIRE
HOT IN ACC OR ON
LEFT RIGHT
LEFT/RIGHT
MIRROR SELECTOR SWITCH
POWER MIRROR SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT POWER MIRROR UP/DOWN
SWITCH 1
SWITCH 3
SWITCH 4
UP LEFT
UP/ RIGHT
UP/ RIGHT SWITCH 2
UP/DOWN
WHT BRN WIRE
WHT WIRE
Go to component -> Power mirror circuit, early production -> LEFT RIGHT
left right wiring diagram (2 of 2)
Go to component -> Power mirror circuit, late production -> LEFT RIGHT
