Honda Passport I (1993-1997) key remind switch powertrain control module Wiring diagram
This page shows the only wiring diagram for the component.key remind switch powertrain control module, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key remind switch powertrain control module (1 of 1)
1994 VFTC
2.6L
2.6L 3.2L
3.2L
A/T ONLY
A/T ONLY M/T ONLY
AUTOMATIC DOOR LOCK CONTROL RELAY
BLK WIRE
BLK/BLU WIRE
BRAKE LIGHT SWITCH
CIRCUIT BREAKER
DASH FUSE BOX
EX ONLY
FROM MAIN FUSE 1 (FUSE/RELAY BOX) (DIAGRAM 2 OF 5)
FUSE 1
FUSE 2
FUSE 3
FUSE 4
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
KEY REMIND SWITCH POWERTRAIN CONTROL MODULE
LEFT FRONT DOOR COURTESY LIGHT RIGHT FRONT DOOR COURTESY LIGHT
LEFT REAR DOOR COURTESY LIGHT
LIGHT SWITCH
LUGGAGE ROOM LIGHT
LX,EX ONLY
POWER WINDOW RELAY
PPL
RADIO
REAR DEFOGGER RELAY
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER BRAKE LIGHT SWITCH
RED WIRE
RED/WHT WIRE
RIGHT REAR DOOR COURTESY LIGHT
SAFETY LOCK CONTROL UNIT
SPOT LIGHT ASSEMBLY DOME LIGHT
TAILGATE OPENER SWITCH
TRANSMISSION CONTROL MODULE
Go to component -> Power distribution circuit, early production (3 of 5) -> KEY REMIND SWITCH POWERTRAIN CONTROL MODULE
