Honda Passport I (1993-1997) hot in start and run Wiring diagram
This page shows the only wiring diagram for the component.hot in start and run, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in start and run (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU/BLK WIRE
DATA LINK CONNECTOR (LEFT KICK PANEL) (2.6L)
DATA LINK CONNECTOR (LEFT KICK PANEL) (3.2L)
DLC IN
ENGINE CONTROL MODULE (BELOW CENTER OF DASH)
FUSE EB-10
FUSE/ RELAY BOX
GRN/BLK WIRE
GRN/YEL WIRE
HOT IN START AND RUN
ORG/BLU WIRE
RED WIRE
TRANSMISSION CONTROL MODULE (BELOW LEFT SIDE OF DASH)
Go to component -> Computer data lines, late production -> HOT IN START AND RUN
