Honda Passport I (1993-1997) hot in on or start under-dash fuse/relay box Wiring diagrams
This page contains all the electrical diagrams for the component. hot in on or start under-dash fuse/relay box, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot in on or start under-dash fuse/relay box (1 of 2)
2.6L
3.2L
A/T M/T
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRAKE LAMP SWITCH
BRAKE WARNING INDICATOR
BRN/RED WIRE
BRN/YEL WIRE
COMBINATION VALVE PRESSURE DIFFERENTIAL SWITCH (LEFT REAR OF ENG COMPARTMENT)
D.G. CONNECTOR (LEFT KICK PANEL)
DIFFERENTIAL SPEED
DIODE BOX D (BEHIND LEFT SIDE OF I/P)
DUMP SOLENOID
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES FUSE 2
HOT IN ACC OR ON FUSE 13
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX
IGNITION IN
INDICATOR SWITCH
INDICATORS
INSTRUMENT CLUSTER
ISOLATION SOLENOID
KICK PANEL)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK/GRN WIRE
PWR IN DUMP SOL
REAR ANTI-LOCK INDICATOR
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER (BELOW RIGHT FRONT SEAT)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RESET SW
RWAL IND ISOLATION SOL SPEED LO IN SPEED HI IN GROUND
RWAL BRAKE VALVE (RIGHT FRONT FENDER)
SENSOR (REAR OF TRANSMISSION)
STOP LIGHTS
TEST CONNECTOR (LEFT
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/PPL WIRE
Go to component -> Anti-lock brake circuits, early production -> HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX
Wiring diagram hot in on or start under-dash fuse/relay box (2 of 2)
2.6L 3.2L
A/T M/T
ALL A/T, M/T W/ CRUISE M/T W/O CRUISE
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRAKE SWITCH
BRAKE WARNING INDICATOR
BRN/RED WIRE
BRN/YEL WIRE
DIFFERENTIAL SPEED
DIODE BOX D (BEHIND LEFT SIDE OF I/P)
DUMP SOLENOID
GRN WIRE
GRY WIRE
HOT AT ALL TIMES STOP CB-13
HOT IN ACC OR ON RWAL CB-23
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX
IGNITION IN
INDICATOR SWITCH
INDICATORS
INSTRUMENT CLUSTER
ISOLATION SOLENOID
KICK PANEL)
LT GRN WIRE
LT GRN/BLK WIRE
METER CB-7
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PARKING BRAKE SWITCH BRAKE DIFFERENTIAL SWITCH (LEFT REAR OF ENG COMPARTMENT)
PNK/BLK WIRE
PNK/GRN WIRE
PWR IN DUMP SOL
REAR ANTI-LOCK INDICATOR
REAR WHEEL ANTI-LOCK BRAKE CONTROLLER (BELOW RIGHT FRONT SEAT)
RED WIRE
RED/GRN WIRE
RESET SW
RWAL IND ISOLATION SOL SPEED LO IN SPEED HI IN GROUND
RWAL BRAKE VALVE (RIGHT FRONT FENDER)
RWAL DIAGNOSTIC CONNECTOR
SENSOR (REAR OF TRANSMISSION)
STOP LIGHTS
TEST CONNECTOR (LEFT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits, late production -> HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX
