Honda Passport I (1993-1997) hot at all times dash fuse box fuse 4 Wiring diagram
This page shows the only wiring diagram for the component.hot at all times dash fuse box fuse 4, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times dash fuse box fuse 4 (1 of 1)
AUTOMATIC DOOR LOCK CONTROL RELAY (RIGHT SIDE KICK PANEL)
AUTOMATIC DOOR LOCK LOCK SWITCH (INSIDE REAR OF LEFT FRONT DOOR)
BLK WIRE
BLK/BLU WIRE
GRN WIRE
HOT AT ALL TIMES DASH FUSE BOX FUSE 4
LEFT REAR AUTOMATIC DOOR LOCK MOTOR
LOCK
RED WIRE
RIGHT FRONT AUTOMATIC DOOR LOCK MOTOR
RIGHT REAR AUTOMATIC DOOR LOCK MOTOR
UNLOCK
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power door lock circuit, early production -> HOT AT ALL TIMES DASH FUSE BOX FUSE 4
