Honda Passport I (1993-1997) gauge assembly vehicle speed output Wiring diagram
This page shows the only wiring diagram for the component.gauge assembly vehicle speed output, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gauge assembly vehicle speed output (1 of 1)
A/T
AUTOMATIC TRANSMISSION MODE SWITCH (LEFT SIDE OF TRANSMISSION)
BACK UP, TURN FUSE CB 15
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE INPUT
BRAKE SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH SWITCH
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL PUMP/ACTUATOR (RIGHT REAR OF ENGINE COMPARTMENT) SAFETY VALVE
CRUISE CONTROL SWITCH
CRUISE CONTROL UNIT (RIGHT KICK PANEL)
CRUISE IND CONTROL
CRUISE MAIN IND
CRUISE ON INPUT VACUUM PUMP/VALVE CONTROL
CRUISE ON OUTPUT
CRUISE SET IND
DASH FUSE BOX (LEFT SIDE OF I/P)
DISENGAGE OUTPUT
ELEC, IG FUSE CB 12
GAUGE ASSEMBLY
GAUGE ASSEMBLY VEHICLE SPEED OUTPUT
GRN (OR WIRE
GRN WIRE
GROUND VACUUM VALVE CONTROL CANCEL INPUT
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION INPUT
LT GRN WIRE
M/T
METER FUSE CB 7
OFF ON
ORG/ WIRE
ORG/BLK WIRE
RED WIRE
RESUME/ ACCEL INPUT
RESUME/ ACCEL SET/ COAST
SET/COAST INPUT
STOP FUSE CB 13
TRANSMISSION CONTROL MODULE (BELOW LEFT SIDE OF I/P) DISENGAGE INPUT
VACUUM PUMP
VACUUM PUMP CONTROL
VEHICLE SPEED INPUT
VENT VALVE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Cruise control circuit, late production -> GAUGE ASSEMBLY VEHICLE SPEED OUTPUT
