Honda Passport I (1993-1997) fuse/ relay box condenser fan relay Wiring diagram
This page shows the only wiring diagram for the component.fuse/ relay box condenser fan relay, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse/ relay box condenser fan relay (1 of 1)
BATTERY
BLK WIRE
BLK/BLU (OR BLK) WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAIDED WIRE
CONDENSER FAN
CRUISE CONTROL PUMP ACTUATOR
DATA LINK CONNECTOR
ECM MAIN RELAY FUEL PUMP RELAY
ELECTRONIC IGNITION ASSEMBLY
ENGINE
ENGINE CONTROL MODULE
FAST IDLE SOLENOID VALVE AIR REGULATOR
FUEL PUMP
FUSE/ RELAY BOX
FUSE/ RELAY BOX CONDENSER FAN RELAY
GRN WIRE
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR SHIELDS
NOISE CONDENSER
POWER SWITCH
SENSING DIAGNOSTIC MODULE
TCM DIAGNOSTIC CONNECTOR
TRAILER LIGHTING CONNECTOR
TRANSMISSION CONTROL MODULE
VALVE COVER)
WHT WIRE
Go to component -> Ground distribution circuit, late production (1 of 3) -> FUSE/ RELAY BOX CONDENSER FAN RELAY
