Honda Passport I (1993-1997) door lock circuit breaker 14 Wiring diagram
This page shows the only wiring diagram for the component.door lock circuit breaker 14, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door lock circuit breaker 14 (1 of 1)
6 8 9 1 2 POWER LCK/UNLCK OUTPUTS RT UNLOCK RT LOCK
BLK WIRE
DASH FUSE BOX
DOOR LOCK CIRCUIT BREAKER 14
DOOR LOCK SWITCH
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT POWER WINDOW, DOOR LOCK SWITCH
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT POWER WINDOW, DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
UNLOCK
WHT WIRE
Go to component -> Power door lock circuit, late production -> DOOR LOCK CIRCUIT BREAKER 14
