Honda Passport I (1993-1997) automatic transmission warning/ indicator assembly Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission warning/ indicator assembly, which is found in the car Honda Passport I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission warning/ indicator assembly (1 of 1)
3.2L 2.6L
A/T ONLY
AUTOMATIC TRANSMISSION MODE SWITCH
AUTOMATIC TRANSMISSION WARNING/ INDICATOR ASSEMBLY
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN/RED WIRE
COMBINATION SWITCH VEHICLE SPEED SENSOR
DASH FUSE BOX
EX ONLY
FROM IGNITION SWITCH (DIAGRAM 1 OF 5 (2.6L)) (DIAGRAM 2 OF 5 (3.2L))
FROM IGNITION SWITCH (DIAGRAM 1 OF 5)
FUEL PUMP AIR REGULATOR
FUEL PUMP RELAY
FUSE 10
FUSE 5
FUSE 6
FUSE 7
FUSE/ RELAY BOX
GRN WIRE
HEATED OXYGEN SENSOR
INSTRUMENT CLUSTER REAR DEFOGGER SWITCH
LT BLU WIRE
LT GRN/WHT WIRE
LX,EX ONLY
MIRROR DEFOGGER SWITCH
REAR WIPER RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
TO FUSES 8&9 (DASH FUSE BOX) (DIAGRAM 5 OF 5)
WARNING BUZZER CONTROL UNIT POWER WINDOW RELAY SAFETY LOCK CONTROL UNIT
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER RELAY CONNECTOR PLUG
WINDSHIELD WIPER/WASHER SWITCH
WITH INTERMITTENT WIPERS W/O INTERMITTENT WIPERS
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit, early production (4 of 5) -> AUTOMATIC TRANSMISSION WARNING/ INDICATOR ASSEMBLY
