Honda Passport I (1993-1997) a/c compressor relay input Wiring diagrams
This page contains all the electrical diagrams for the component. a/c compressor relay input, in which he is found in the car Honda Passport I (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c compressor relay input (1 of 2)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR RELAY
A/C COMPRESSOR RELAY CNTL
A/C COMPRESSOR RELAY INPUT
A/C ON INPUT
A/C REQUEST IN
A/C SWITCH
A/C THERMO SWITCH (LEFT FRONT CORNER OF ENGINE COMPARTMENT)
A/C THERMOSTAT RELAY (RIGHT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
CONDENSER FAN FUSE
CONDENSER FAN RELAY (RIGHT SIDE OF ENGINE COMPARTMENT)
DIODE BOX B
ENGINE CONTROL MODULE (ECM) (BEHIND LEFT SIDE KICK PANEL)
FUSE/ RELAY BOX
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LT GRN/YEL WIRE
NOISE CONDENSER (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
PNK/WHT WIRE
TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
WHT WIRE
Go to component -> 3.2l, a/c circuit, early production (1 of 2) -> A/C COMPRESSOR RELAY INPUT
Wiring diagram a/c compressor relay input (2 of 2)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR RELAY
A/C COMPRESSOR RELAY CNTL
A/C COMPRESSOR RELAY INPUT
A/C ON INPUT
A/C SWITCH
A/C THERMO SWITCH (LEFT FRONT CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
COND FAN FUSE
CONDENSER FAN (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
CONDENSER FAN RELAY
ENGINE CONTROL MODULE (ECM) (BEHIND LEFT SIDE KICK PANEL)
FUSE/ RELAY BOX
FUSE/RELAY BOX
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LT GRN/BLK WIRE
NOISE CONDENSER (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
PNK/WHT WIRE
THERMO SWITCH RELAY
TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
WHT WIRE
Go to component -> 3.2l, a/c circuit, late production (1 of 2) -> A/C COMPRESSOR RELAY INPUT
