Car Wiring Diagrams for Starting circuit for Honda Odyssey V facelift (2017-2020)

12 VOLT BATTERY 12 VOLT BATTERY SENSOR 12 VOLT BATTERY TERMINAL FUSE BOX BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 16 FUSE 26 FUSE AA FUSE AD GRN WIRE LT BLU WIRE MAGNETIC SWITCH ON BATTERY) PCM PPL ST CUT DIODE STARTER STARTER CUT RELAY 1 STARTER CUT RELAY 2 UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT) WHT WIRE

10 SPEED A/T BLK WIRE BODY CONTROL MODULE COMPUTER DATA LINES SYSTEM ENGINE START/STOP SWITCH FUSE 1-4 FUSE 16 FUSE 34 FUSE HOLDER GRN WIRE GRY WIRE LT BLU WIRE RED WIRE RELAY ENERGIZED TRANSMISSION CONTROL MODULE UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE
