Car Wiring Diagrams for Entry light timer circuit for Honda Odyssey V facelift (2017-2020)

BLK WIRE BLU WIRE COURTESY LAMPS CIRCUIT DRIVER'S VANITY MIRROR LIGHT FRONT INDIVIDUAL MAP LIGHT FUSE 15 FUSE 20 HOT AT ALL TIMES INTERIOR LIGHT MOONROOF SWITCH LT BLU WIRE OFF ON OFF OFF PASSENGER'S VANITY MIRROR LIGHT PNK WIRE POWER DISTRIBUTION MODULE PPL RED WIRE SMART FET UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BODY CONTROL MODULE COMPUTER DATA LINES SYSTEM DOOR LOCK KNOB DOOR MULTIPLEX CONTROL UNIT DRIVER'S DOOR DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR SWITCH FUSE 34 GAUGE CONTROL MODULE GRN WIRE GRY WIRE KEY LEFT SLIDING DOOR SWITCH LOCK LOCK KNOB SWITCH LT BLU WIRE PNK W/ POWER TAILGATE WIRE PNK W/O POWER TAILGATE WIRE PNK WIRE POWER TAILGATE CLOSER UNIT POWER TAILGATE CONTROL UNIT POWER WINDOW MASTER SWITCH RELAY ENERGIZED RIGHT SLIDING DOOR SWITCH TAILGATE LATCH SWITCH/ TAILGATE RELEASE ACTUATOR TAN WIRE UNDER-DASH FUSE/RELAY BOX UNLOCK WHT WIRE YEL WIRE
