Wiring Diagrams for Honda Odyssey V facelift 2 (2020-2024)

Engine mount control unit circuit Grille shutter circuit

Automatic a/c circuit

Anti-lock brakes circuit

Anti-theft circuit

Body control module circuit Power distribution module circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Heated windshield circuit Mirror heater & rear defogger circuit

Electronic power steering circuit

Wiring diagram engine performance 3.5l

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Entry light timer circuit Instrument illumination circuit

Memory mirrors circuit Memory seat circuit

Blind spot information system circuit Hands free module circuit Home link remote control circuit Lane watch camera circuit Multipurpose camera circuit Navigation circuit, 11 speakers Navigation circuit, 7 speakers Parking assistant circuit Rear camera circuit

Power distribution circuit

Power door locks circuit

Automatic day/night mirror circuit Power mirrors circuit

Driver power seat circuit Driver"s lumbar circuit Front ventilation & heated seat circuit Heated steering wheel circuit Passenger power seat circuit Passenger"s lumbar circuit

Power top/sunroof circuit

Power windows circuit, front power windows auto up/down function Power windows circuit, front & rear power windows auto up/down function

Radio circuit, w/ color audio Radio circuit, w/ display audio & 11 speakers Radio circuit, w/ display audio & 7 speakers

Electric parking brake circuit Shift interlock circuit

Charging circuit Starting circuit

Supplemental restraints circuit

Transmission circuit

Power sliding door circuit Power tailgate circuit Tailgate & fuel door release circuit

Chime circuit Tire pressure monitoring circuit

Front wiper/washer circuit Rear wiper/washer circuit

12 VOLT BATTERY ACC DIODE ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES, DOOR LOCKS, ANTI-THEFT, INTERIOR LIGHTS SYSTEMS B-CAN TRANSCEIVER BACK LT DIODE CRUISE CONTROL, ANTI-LOCK BRAKES SYSTEMS DIODE A DOOR LOCK KNOB ELECTRIC STEERING LOCK F-CAN TRANSCEIVER IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGPS DIODE LIN TRANSCEIVER ON BATTERY) ST CUT DIODE STEREO AMPLIFIER W/O ELECTRIC STEERING LOCK

12 VOLT BATTERY FAN MOTOR A/C CONDENSER FAN MOTOR AIR MIX CONTROL MOTOR CLOSER MOTOR CLOSER/ RELEASE MOTOR DRIVER'S DOOR LOCK ACTUATOR DRIVER'S POWER LUMBAR SUPPORT MOTOR DRIVER'S POWER WINDOW MOTOR DRIVER'S SEAT CUSHION BLOWER MOTOR DRIVER'S SEAT FRONT UP-DOWN MOTOR/ POSITION MOTOR DRIVER'S SEAT RECLINE MOTOR/ POSITION MOTOR DRIVER'S SEAT SLIDE MOTOR/ POSITION MOTOR DRIVER'S SEAT UP-DOWN MOTOR/ POSITION MOTOR DRIVER'S SEAT-BACK BLOWER MOTOR ENGINE BLOCK) ENGINE CONTROLS SYSTEM EPS MOTOR FRONT BLOWER MOTOR FRONT ENGINE MOUNT ACTUATOR FRONT PASSENGER'S DOOR LOCK ACTUATOR FRONT PASSENGER'S POWER LUMBAR SUPPORT MOTOR FRONT PASSENGER'S POWER WINDOW MOTOR FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR FRONT PASSENGER'S SEAT RECLINE MOTOR FRONT PASSENGER'S SEAT SLIDE MOTOR FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR FUEL FILL DOOR LOCK ACTUATOR HONDAVAC MOTOR LEFT POWER SLIDING MOTOR LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR LEFT REAR POWER WINDOW MOTOR LEFT SLIDING DOOR LOCK ACTUATOR LEFT/RIGHT MOTOR MIRROR ACTUATOR MODE CONTROL MOTOR A MODE CONTROL MOTOR B MOTOR DRIVE IC PASSENGER'S AIR MIX CONTROL MOTOR POWER LUMBAR SUPPORT MOTOR A POWER LUMBAR SUPPORT MOTOR B POWER TAILGATE MOTOR RADIATOR FAN MOTOR REAR AIR MIX CONTROL MOTOR REAR BLOWER MOTOR REAR ENGINE MOUNT ACTUATOR REAR MODE CONTROL MOTOR REAR WINDOW WIPER MOTOR RECIRCULATION CONTROL MOTOR RETRACT ACTUATOR RIGHT POWER SLIDING MOTOR RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR RIGHT REAR POWER WINDOW MOTOR RIGHT SLIDING DOOR LOCK ACTUATOR TAILGATE RELEASE ACTUATOR THROTTLE ACTUATOR UP/DOWN MOTOR WINDSHIELD/ REAR WINDOW WASHER MOTOR

FRONT INTERIOR LF ANTENNA LEFT FRONT LF ANTENNA/INITIATOR LEFT REAR LF ANTENNA/INITIATOR LF ANTENNA MIDDLE INTERIOR LF ANTENNA REAR INTERIOR LF ANTENNA RIGHT FRONT LF ANTENNA/ INITIATOR RIGHT FRONT LF ANTENNA/INITIATOR RIGHT REAR LF ANTENNA/INITIATOR ROOF ANTENNA WINDOW ANTENNA WINDOW ANTENNA AMPLIFIER

CABIN WATCH CAMERA LANE WATCH CAMERA REAR VIEW CAMERA

5 PIN CONNECTOR, 4 PIN CONNECTOR 6 PIN CONNECTOR 12-PIN CONNECTOR CARGO AREA ACCESSORY POWER SOCKET FRONT ACCESSORY POWER SOCKET LEFT REAR ACCESSORY POWER SOCKET OPTIONAL CONNECTOR OPTIONAL CONNECTOR C DOOR RIGHT REAR ACCESSORY POWER SOCKET

BODY CONTROL MODULE BODY CONTROL MODULE CIRCUIT GAUGE CONTROL MODULE SBW SHIFTER CONTROL MODULE TRANSMISSION CONTROL MODULE

AC INVERTER UNIT ANC/ ACTIVE SOUND CONTROL UNIT ANC/ACTIVE SOUND CONTROL UNIT AUDIO UNIT AUTO TURN UNIT BD PLAYER UNIT CENTER DISPLAY UNIT CLIMATE CONTROL UNIT CONTROL UNIT) DOOR MULTIPLEX CONTROL UNIT DOOR MULTIPLEX CONTROL UNIT POWER WINDOW MASTER SWITCH ENGINE MOUNT CONTROL UNIT EPS CONTROL UNIT FUEL TANK UNIT HEATED STEERING WHEEL CONTROL UNIT HOMELINK UNIT INFOTAINMENT CONTROL UNIT LEFT POWER SLIDING DOOR CONTROL UNIT LEFT SIDE BSI RADAR UNIT MOONROOF MOTOR/ CONTROL UNIT MULTI-PURPOSE CAMERA UNIT POWER MIRROR CONTROL UNIT POWER SEAT CONTROL UNIT POWER TAILGATE CLOSER UNIT POWER TAILGATE CONTROL UNIT RES CONTROL UNIT RIGHT POWER SLIDING DOOR CONTROL UNIT RIGHT SIDE BSI RADAR UNIT SRS UNIT TELEMATICS CONTROL UNIT TELEMATICS SWITCH UNIT TUNER AMPLIFIER UNIT TUNER UNIT USB CHARGER UNIT VENTILATED SEAT/ SEAT HEATER CONTROL UNIT VENTILATED SEAT/SEAT HEATER CONTROL UNIT VSA MODULATOR CONTROL UNIT WINDSHIELD WIPER CONTROL UNIT/MOTOR

12 VOLT BATTERY TERMINAL FUSE BOX FUSE 1 FUSE 1-2 FUSE 1-3 FUSE 1-4 FUSE 1-5 FUSE 1-6 FUSE 1-7 FUSE 1-8 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 34 FUSE 35 FUSE 36 FUSE 37 FUSE 38 FUSE 39 FUSE AA FUSE AB FUSE AC FUSE AD FUSE AE FUSE EA FUSE EB FUSE EC FUSE ED FUSE EE FUSE EF FUSE EG FUSE HOLDER

LEFT HEADLIGHT RIGHT HEADLIGHT

DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT- BACK HEATER FRONT PASSENGER'S SEAT BACK HEATER FRONT PASSENGER'S SEAT CUSHION HEATER

BRAKE SYSTEM INDICATOR CHARGING SYSTEM INDICATOR FRONT FOG LIGHT INDICATOR FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HEATED STEERING WHEEL INDICATOR HIGH BEAM INDICATOR LEFT BSI ALERT INDICATOR LEFT TURN SIGNAL INDICATOR LIGHTS ON INDICATOR LOW OIL PRESSURE INDICATOR POWER SLIDING DOOR INDICATOR RIGHT BSI ALERT INDICATOR RIGHT TURN SIGNAL INDICATOR SEAT BELT REMINDER INDICATOR SECURITY INDICATOR SRS INDICATOR TPMS INDICATOR

DOOR LOCKS, ANTI-THEFT, INTERIOR LIGHTS SYSTEMS DOOR LOCKS, ANTI-THEFT, INTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS EXTERIOR LIGHTS, MIRRORS SYSTEMS INTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS

HIGH PRESSURE FUEL PUMP HIGH PRESSURE FUEL PUMP SHIELD

A/C CONDENSER FAN RELAY ACC RELAY BRAKE LIGHT RELAY CARGO AREA ACCESSORY POWER SOCKET RELAY CLOSE RELAY DC-DC CONVERTER ACC RELAY ELECTRONIC THROTTLE CONTROL SYSTEM RELAY FAN CONTROL RELAY FRONT ACCESSORY POWER SOCKET RELAY FUEL FILL DOOR LOCK ACTUATOR RELAY FUSE/ RELAY HOLDER A FUSE/ RELAY HOLDER B FUSE/RELAY HOLDER A FUSE/RELAY HOLDER B HEATED STEERING WHEEL RELAY HEATED WINDSHIELD WIPER AREA RELAY HOT W/ ACC RELAY ENERGIZED HOT W/ DC-DC CONVERTER ACC RELAY 1 ENERGIZED HOT W/ PGM-FI MAIN RELAY 1 ENERGIZED INJECTOR RELAY LEFT REAR ACCESSORY POWER SOCKET RELAY LEFT REAR POWER WINDOW RELAY LEFT REAR POWER WINDOW RELAY RELAY HOLDER B LEFT SLIDING DOOR LOCK RELAY LEFT SLIDING DOOR UNLOCK RELAY MOTOR RELAY OPEN RELAY PGM-FI MAIN RELAY 1 RADIATOR FAN RELAY REAR ACCESSORY POWER SOCKET RELAY REAR WINDOW DEFOGGER RELAY REAR WINDOW WASHER MOTOR RELAY RELAY 1 ENERGIZED RELAY 2 ENERGIZED RELAY ENERGIZED RELAY HOLDER A REVERSE RELAY RIGHT REAR POWER WINDOW RELAY RIGHT REAR POWER WINDOW RELAY RELAY HOLDER B STARTER CUT RELAY 1 STARTER CUT RELAY 2 TAILGATE RELEASE ACTUATOR RELAY UNDER- DASH FUSE/ RELAY BOX UNDER- HOOD FUSE/ RELAY BOX UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WINDSHIELD WASHER MOTOR RELAY

12 VOLT BATTERY SENSOR A/C PRESSURE SENSOR APP SENSOR APP SENSOR A APP SENSOR B ATF TEMPERATURE SENSOR AUTOMATIC LIGHTING CONTROL UNIT-SENSOR AUTOMATIC LIGHTING/ RAIN SENSOR AUTOMATIC LIGHTING/RAIN SENSOR CKP SENSOR CMP SENSOR COUNTERSHAFT SPEED SENSOR DRIVER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SWITCH DRIVER'S SEAT FRONT UP-DOWN MOTOR/ POSITION SENSOR DRIVER'S SEAT POSITION SENSOR DRIVER'S SEAT RECLINE MOTOR/ POSITION SENSOR DRIVER'S SEAT SLIDE MOTOR/POSITION SENSOR DRIVER'S SEAT UP-DOWN MOTOR/ POSITION SENSOR ECT SENSOR 1 ECT SENSOR 2 EGR VALVE POSITION SENSOR FRONT EVAPORATOR TEMPERATURE SENSOR FRONT PASSENGER'S DOOR OUTER HANDLE TOUCH SENSOR/ LOCK SWITCH FRONT PASSENGER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SWITCH FTP SENSOR FUEL RAIL PRESSURE SENSOR HALL SENSOR HANDS FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR HUMIDITY/IN-CAR TEMPERATURE SENSOR KNOCK SENSOR 1 BANK 1 KNOCK SENSOR 2 BANK 2 LEFT FRONT CENTER SENSOR LEFT FRONT CORNER SENSOR LEFT FRONT IMPACT SENSOR LEFT FRONT WHEEL SPEED SENSOR LEFT POWER SLIDING DOOR PINCH SENSOR LEFT POWER TAILGATE PINCH SENSOR LEFT REAR CENTER SENSOR LEFT REAR CORNER SENSOR LEFT REAR WHEEL SPEED SENSOR LEFT SLIDING DOOR OUTER HANDLE TOUCH SENSOR MAF/IAT SENSOR MAINSHAFT SPEED SENSOR MAP SENSOR MOTOR ANGLE SENSOR MOTOR ANGLE SENSOR, BRAKE PEDAL STROKE SENSOR OUTSIDE AIR TEMPERATURE SENSOR PARKING ACTUATOR VALVE STROKE SENSOR PARKING, BACKUP SENSOR CONTROL UNIT PARKING, BACKUP SENSOR SWITCH PARKING, BACKUP SENSOR SWITCH/ SAFETY SUPPORT SWITCH PARKING, BACKUP SENSOR SWITCH/ VSA OFF SWITCH POSITION SENSOR POWER TAILGATE SENSOR REAR EVAPORATOR TEMPERATURE SENSOR REAR SAFING SENSOR RIGHT FRONT CENTER SENSOR RIGHT FRONT CORNER SENSOR RIGHT FRONT IMPACT SENSOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT POWER SLIDING DOOR PINCH SENSOR RIGHT POWER TAILGATE PINCH SENSOR RIGHT REAR CENTER SENSOR RIGHT REAR CORNER SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT SLIDING DOOR OUTER HANDLE TOUCH SENSOR ROCKER ARM OIL PRESSURE SENSOR SLIDING MOTOR SENSOR STEERING ANGLE SENSOR STEERING HEATER/ TEMPERATURE SENSOR SUNLIGHT SENSOR THROTTLE OPEN SENSOR TORQUE SENSOR TOUCH SENSOR TRANSMISSION FLUID PRESSURE SENSOR A TRANSMISSION FLUID PRESSURE SENSOR B TRANSMISSION FLUID PRESSURE SENSOR C TRANSMISSION FLUID PRESSURE SENSOR D TRANSMISSION FLUID PRESSURE SENSOR E TRANSMISSION FLUID PRESSURE SENSOR F TWO-WAY CLUTCH ACTUATOR VALVE STROKE SENSOR W/ HANDLE FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR W/ HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR W/O HANDLE FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR W/O HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR

7 SPEAKER 11 SPEAKER CENTER ROOF SPEAKER DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT SATELLITE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT SATELLITE SPEAKER

ACC COMBINATION SWITCH APPLY SWITCH AUDIO REMOTE- HFL SWITCH AUTOMATIC BRAKE HOLD SWITCH BRAKE FLUID LEVEL SWITCH BRAKE PEDAL POSITION SWITCH CANCEL SWITCH CHILDPROOF LOCK SWITCH CMBS OFF SWITCH/ RDM SWITCH COMBINATION LIGHT SWITCH DIMMER SWITCH DISTANCE SWITCH DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/KEY CYLINDER SWITCH DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH DRIVER'S POWER LUMBAR SUPPORT SWITCH DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRIVER'S POWER SLIDING DOOR SWITCH DRIVER'S POWER TAILGATE SWITCH DRIVER'S SEAT BELT BUCKLE SWITCH DRIVER'S SEAT HEATER SWITCH DRIVER'S SWITCH DRIVER'S VENTILATED SEAT/SEAT HEATER SWITCH DRIVING POSITION MEMORY SWITCH ECON SWITCH/ SNOW SWITCH/ IDLE STOP OFF SWITCH ECON SWITCH/SNOW SWITCH/ IDLE STOP OFF SWITCH ECON/ SNOW SWITCH/ IDLE STOP OFF SWITCH ECON/SNOW/ IDLE STOP OFF SWITCH ELECTRIC PARKING BRAKE SWITCH ENGINE START/STOP SWITCH FRONT FOG LIGHT SWITCH FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S POWER LUMBAR SUPPORT SWITCH FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FRONT PASSENGER'S SEAT HEATER SWITCH FRONT PASSENGER'S SWITCH FRONT PASSENGER'S VENTILATED SEAT/SEAT HEATER SWITCH FRONT UP-DOWN SWITCH FUEL FILL DOOR SWITCH FUEL FILL DOOR SWITCH/ FUEL FILL DOOR LOCK ACTUATOR FULL LATCH SWITCH HALF LATCH SWITCH HEADLIGHT SWITCH HEATED STEERING WHEEL SWITCH HEATED WINDSHIELD WIPER AREA SWITCH HONDAVAC SWITCH HOOD LATCH SWITCH HORN SWITCH INTERIOR LIGHT MOONROOF SWITCH INTERIOR LIGHT SWITCH INTERIOR LIGHT/MOONROOF SWITCH KEY CYLINDER SWITCH LANE WATCH SWITCH LEFT B-PILLAR POWER SLIDING DOOR SWITCH LEFT POWER SLIDING DOOR REMOTE CONTROL SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SWITCH LEFT SLIDING DOOR LOCK ACTUATOR/ KNOB SWITCH LEFT SLIDING DOOR LOCK ACTUATOR/KNOB SWITCH LEFT SLIDING DOOR SWITCH LKAS SWITCH LOCK KNOB SWITCH LOCK SWITCH LOWER LATCH RELEASE SWITCH MAGNETIC SWITCH MAIN SWITCH NEUTRAL SWITCH NEUTRAL SWITCH 1 NEUTRAL SWITCH 2 OUTER HANDLE SWITCH POWER LUMBAR SUPPORT SWITCH POWER MIRROR SWITCH POWER TAILGATE INSIDE SWITCH POWER WINDOW MASTER SWITCH RATCHET SWITCH REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH REAR WIPER/ WASHER SWITCH RECLINE SWITCH RELEASE SWITCH REMOTE CONTROL SWITCH 1 REMOTE CONTROL SWITCH 2 REMOTE CONTROL SWITCH 3 RES/+ SWITCH RIGHT B-PILLAR POWER SLIDING DOOR SWITCH RIGHT POWER SLIDING DOOR REMOTE CONTROL SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SWITCH RIGHT SLIDING DOOR LOCK ACTUATOR/ KNOB SWITCH RIGHT SLIDING DOOR LOCK ACTUATOR/KNOB SWITCH RIGHT SLIDING DOOR SWITCH SAFETY SUPPORT SWITCH/ VSA OFF SWITCH SET SWITCH SLIDE SWITCH SWITCH 1 SWITCH 2 SWITCH 3 SWITCH 3 SWITCH 1 TAILGATE LATCH SWITCH TAILGATE LATCH SWITCH/ TAILGATE RELEASE ACTUATOR TAILGATE LATCH SWITCH/TAILGATE RELEASE ACTUATOR TAILGATE OUTER HANDLE/ LOCK SWITCH/ LICENSE PLATE TAILGATE OUTER HANDLE/LOCK SWITCH/LICENSE PLATE LIGHT TELEMATICS SWITCH MODULE TILT SWITCH TRANSMISSION FLUID PRESSURE SWITCH TURN SIGNAL SWITCH UP/DOWN SWITCH VSA OFF SWITCH VSA OFF SWITCH/ SAFETY SUPPORT SWITCH VSA OFF/HEATED WINDSHIELD WIPER AREA SWITCH WASHER FLUID LEVEL SWITCH WASHER SWITCH WINDSHIELD WIPER SWITCH WIPER/WASHER SWITCH

CLUTCH PRESSURE CONTROL SOLENOID VALVE A CLUTCH PRESSURE CONTROL SOLENOID VALVE B CLUTCH PRESSURE CONTROL SOLENOID VALVE C CLUTCH PRESSURE CONTROL SOLENOID VALVE D CLUTCH PRESSURE CONTROL SOLENOID VALVE E CLUTCH PRESSURE CONTROL SOLENOID VALVE F CLUTCH PRESSURE CONTROL SOLENOID VALVE G CLUTCH PRESSURE CONTROL SOLENOID VALVE H EGR VALVE EVAP CANISTER PURGE VALVE EVAP CANISTER VENT SHUT VALVE SHIFT SOLENOID VALVE A SHIFT SOLENOID VALVE B SHIFT SOLENOID VALVE C SHIFT SOLENOID VALVE D SHIFT SOLENOID VALVE E SHIFT SOLENOID VALVE F SHIFT SOLENOID VALVE G VARIABLE CAPACITY CONTROL SOLENOID

(OR RED/ WIRE BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE LT PNK WIRE NCA WIRE ORG/ WIRE PNK W/ POWER TAILGATE WIRE PNK W/O POWER TAILGATE WIRE PNK WIRE PPL PNK WIRE PPL/BLU WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE RED WIRE TAN WIRE WHT WIRE YEL WIRE

0) LOW 1) HIGH 2) PASS 0) OFF 1) ON 0) OFF 1) PARK 2) AUTO 3) HEAD 7 SPEAKERS 7 SPEAKERS 11 SPEAKERS A/C COMPRESSOR AC POWER OUTLET AIR CONDITIONING SYSTEM AMBIENT LIGHT ASSIST) AUTO AUTO CLOSE OPEN AUTO AUTO OPEN CLOSE AUTO DOWN AUTO UP AUTOMATIC DAY/ NIGHT MIRROR CIRCUIT AUTOMATIC DIMMING INSIDE MIRROR AUXILIARY JACK ASSEMBLY B-CAN B-CAN H B-CAN H B-CAN L B-CAN L CABLE REEL CAN GATEWAY CAN L CARGO AREA LIGHT CENTER DASH BOARD DECORATION LIGHT CLOSE OPEN COMPUTER DATA LINES SYSTEM CONSOLE BOX LIGHT COOLING FANS SYSTEM COURTESY LAMPS CIRCUIT CRUISE CONTROL SYSTEM DC-DC CONVERTER DEFOGGER SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DRIVER'S DASH BOARD DECORATION LIGHT DRIVER'S DOOR DRIVER'S DOOR COURTESY LIGHT DRIVER'S DOOR INNER HANDLE LIGHT DRIVER'S DOOR POCKET LIGHT DRIVER'S FOOTWELL LIGHT DRIVER'S KNEE AIR BAG INFLATOR DRIVER'S SEAT BELT TENSIONER DRIVER'S SIDE AIR BAG INFLATOR DRIVER'S VANITY MIRROR LIGHT ECON SNOW ELECTRIC BRAKE BOOSTER ENTER DOWN ENTER LEFT EXCEPT LX F CAN JUNCTION A F-CAN F-CAN H F-CAN L FLOOR B-CAN JUNCTION B FLOOR JUNCTION FRONT HFL-ANC/ ACTIVE SOUND CONTROL MICROPHONE FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE FRONT INDIVIDUAL MAP LIGHT FRONT PASSENGER'S AIR BAG ACTIVE VENT TETHER CUTTER FRONT PASSENGER'S AIR BAG INFLATOR FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S DOOR INNER HANDLE LIGHT FRONT PASSENGER'S DOOR POCKET LIGHT FRONT PASSENGER'S KNEE AIR BAG INFLATOR FRONT PASSENGER'S SEAT BELT TENSIONER FRONT PASSENGER'S SIDE AIR BAG INFLATOR FRONT POWER TRANSISTOR FRONT POWER WINDOWS AUTO UP/DOWN FUNCTION FRONT, REAR POWER WINDOWS AUTO UP/DOWN FUNCTION GENERAL JUNCTION GLOVE BOX LIGHT HANDS FREE MODULE CIRCUIT HDMI PORT LIGHT HEADLIGHTS SYSTEM HEATED WINDSHIELD WIPER AREA HIGH MOUNT BRAKE LIGHT HORNS SYSTEM HOT AT ALL TIMES HOT DC-DC HOT W/ HOT W/ DC-DC HOT W/ DC-DC CONVERTER IDLE STOP ILLUMINATION CONTROL ILLUMINATION JUNCTION A ILLUMINATION JUNCTION B IND 1 IND 2 IND LED INJECTOR 1 INJECTOR 1 SHIELD INJECTOR 2 INJECTOR 2 SHIELD INJECTOR 3 INJECTOR 3 SHIELD INJECTOR 4 INJECTOR 4 SHIELD INJECTOR 5 INJECTOR 5 SHIELD INJECTOR 6 SHIELD INJECTOR 6) INSTRUMENT CLUSTER SYSTEM INTERMITTENT DWELL TIME CONTROLLER KEYLESS BUZZER LEFT BACKUP LIGHT LEFT BRAKE LIGHT LEFT CESS ARTICULATED HARNESS LEFT CLOSE LEFT FOG LIGHT LEFT FRONT DOOR TWEETER LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT INNER TAILLIGHT LEFT LEFT RIGHT LEFT OPEN LEFT POWER MIRROR LEFT REAR TURN SIGNAL LIGHT LEFT RES AUXILIARY JACK ASSEMBLY LEFT RIGHT LEFT SIDE CURTAIN AIR BAG INFLATOR LEFT SIDE TURN SIGNAL LIGHT LEFT SLIDING DOOR REAR LATCH LEFT TAILLIGHT/ SIDE MARKER LIGHT LICENSE PLATE LIGHT MILLIMETER WAVE RADAR MIRROR DEFOGGER MIRRORS SYSTEM MOST I/F NAVIGATION SYSTEM NAVIGATION, SOUND SYSTEMS OFF HOOK OFF OPEN CLOSE ON HOOK ON OFF OFF OPEN CLOSE PASSENGER'S DASH BOARD DECORATION LIGHT PASSENGER'S FOOTWELL LIGHT PASSENGER'S VANITY MIRROR LIGHT POSITION 1 POSITION 2 POWER DISTRIBUTION MODULE POWER DISTRIBUTION SYSTEM POWER MIRROR DEFOGGER POWER SLIDING DOOR CIRCUIT POWER WINDOWS SYSTEM REAR ANC/ ACTIVE SOUND CONTROL MICROPHONE REAR CLIMATE CONTROL PANEL REAR CONTROL BLOCK REAR POWER TRANSISTOR REAR SIDE MARKER LIGHT REAR VIEW MIRROR) REAR WINDOW DEFOGGER RES SCREEN RIGHT B-CAN JUNCTION RIGHT BACKUP LIGHT RIGHT BRAKE LIGHT RIGHT CESS ARTICULATED HARNESS RIGHT CLOSE RIGHT END OF DASH) RIGHT FOG LIGHT RIGHT FRONT DOOR TWEETER RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT INNER TAILLIGHT RIGHT OPEN RIGHT POWER MIRROR RIGHT REAR TURN SIGNAL LIGHT RIGHT RES AUXILIARY JACK ASSEMBLY RIGHT SIDE CURTAIN AIR BAG INFLATOR RIGHT SIDE OF RADIATOR) RIGHT SIDE TURN SIGNAL LIGHT RIGHT SLIDING DOOR REAR LATCH RIGHT TAILLIGHT/ SIDE MARKER LIGHT SEATS SYSTEM SET- SHUTTER GRILLE SLIDING DOOR BUZZER SMART FET SOUND SYSTEMS SPARK PLUG STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TAIL- LIGHT TALK HOME THERMAL JOINT 1 THERMAL JOINT 2 TRANSMISSION HOUSING) TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM USB PORT A LIGHT USB PORT/ AUXILIARY JACK ASSEMBLY USB PORT/AUXILIARY JACK ASSEMBLY VOL DOWN VOL DOWN VOL UP VOL UP VOL UP UP W/ AUTOMATIC DIMMING OUTSIDE MIRROR W/ BSI W/ CLIMATE CONTROL W/ DISPLAY AUDIO W/ KEYLESS ACCESS SYSTEM W/ LANE WATCH W/ LANE WATCH W/O MEMORY W/ LANE WATCH, MEMORY W/ LED W/O LED W/ MEMORY W/ MOONROOF W/ NAVIGATION W/ POWER TAILGATE W/ SEAT HEATERS W/ TELEMATICS W/O AUTOMATIC DIMMING OUTSIDE MIRROR W/O BSI W/O KEYLESS ACCESS FUNCTION W/ KEYLESS ACCESS FUNCTION W/O KEYLESS ACCESS SYSTEM W/O LANE WATCH W/O LANE WATCH W/ AUTOMATIC DIMMING OUTSIDE MIRROR W/O LANE WATCH W/ LANE WATCH W/O MEMORY W/ LANE WATCH, MEMORY W/O LANE WATCH, AUTOMATIC DIMMING OUTSIDE MIRROR W/O MEMORY W/O MOONROOF W/O NAVIGATION W/O POWER TAILGATE W/O POWER TAILGATE, DISPLAY AUDIO W/ POWER TAILGATE W/O SEAT HEATERS W/O TELEMATICS W/O VENTILATION WIPER/WASHER SYSTEM WIRELESS CHARGER
