Supplemental restraints circuit for Honda Odyssey V (2013-2017)
Supplemental restraints circuit (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
DRIVER'S JUNCTION BOX 1
DRIVER'S UNDER-DASH FUSE/RELAY BOX
F-CAN H
F-CAN L
FRONT PASSENGER'S AIR BAG FIRST INFLATOR
FRONT PASSENGER'S AIR BAG SECOND INFLATOR
FUSE 11
FUSE 19
FUSE 23 24
GRN WIRE
HOT IN ON OR START
LEFT FRONT IMPACT SENSOR
LFS-
LT BLU WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PPL
PTT
RED WIRE
RED/WHT WIRE
RFS-
RIGHT FRONT IMPACT SENSOR
SHORTING BAR
SRS GND 2
SRS GRD 1
SRS UNIT
STEERING WHEEL)
W/O KEYLESS ACCESS W/ KEYLESS ACCESS
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Supplemental restraints circuit (2 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
F-CAN TRANSCEIVER
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR (FRONT OUTER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR (REAR OUTER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR UNIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
KLINE
LT BLU WIRE
LT GRN WIRE
ODUS
ORG/ WIRE
POW
RED WIRE
SEAT BELT REMINDER INDICATOR
SIDE AIR BAG OFF INDICATOR (USA) SIDE AIR BAG CUT-OFF INDICATOR (CANADA)
SRS INDICATOR
TURN SIGNAL, HAZARD WARNING LIGHTS
WHT WIRE
YEL WIRE
Supplemental restraints circuit (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT BELT OUTER LAP TENSIONER
DRIVER'S SEAT BELT TENSIONER
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SIDE AIR BAG INFLATOR
FLBC
FRBC
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
LEFT SIDE CURTAIN AIR BAG INFLATOR
LLP-
LRP-
LSA -
LT BLU WIRE
LT GRN WIRE
ODS
ORG/ WIRE
REAR SAFING SENSOR (CENTER OF CARGO AREA FLOOR)
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR
RRP
RSA-
SHORTING BAR
SRS UNIT
SS+
SSS
W/ MEMORY
W/O MEMORY
WHT WIRE
YEL WIRE
