Radio circuit, w/ navigation for Honda Odyssey V (2013-2017)

+B RADIO ANT B+ AUDIO- NAVIGATION UNIT B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 1 DRIVER'S UNDER-DASH FUSE/RELAY BOX FL PRE- FR PRE- FUSE 13 FUSE 15 GPS ANTENNA GPS SIG GPS SIG GND GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON K LINE LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE PPL PREMIUM RADIO SW +B RDS-TMC ANTENNA AMPLIFIER REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE REMOTE + REMOTE GND REMOTE SW RF IN RF SH RL PRE- RR PRE- SH (SPDIF) SPDIF (-) TMC SIG UNDER-HOOD FUSE/RELAY BOX USB DATA - USB GND USB PORT USB SH USB VBUS WHT WIRE WINDOW ANTENNA (RDS TMC)

AUDIO REMOTE SWITCH BASE W/ MEMORY, PREMIUM BASE W/O MEMORY BLK WIRE BLU WIRE BRN WIRE CABLE REEL CENTER SWITCH PANEL CHANNEL DOWN SWITCH CHANNEL UP SWITCH DISPLAY BUTTON FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE HFL- NAVIGATION VOICE CONTROL SWITCH ILLUMI (-) INTERIOR LIGHTS JOG JOG SH LT BLU WIRE LT GRN WIRE MODE SWITCH OFF HOOK BUTTON ON HOOK/ BACK BUTTON ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT TWEETER STEERING WHEEL) SYSTEM TALK BUTTON VOLUME DOWN SWITCH VOLUME UP SWITCH W/O MEMORY W/ MEMORY PREMIUM BASE WHT WIRE

AUDIO- NAVIGATION UNIT AUX DET AUX GND AUX LCH AUX RCH AUX SH GND AUX SIG GND AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT CESS ARTICULATED HARNESS LEFT REAR DOOR SPEAKER LEFT SATELLITE SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL PREMIUM PREMIUM BASE RED WIRE RG GND RG L+ RG SH RIGHT CESS ARTICULATED HARNESS RIGHT REAR DOOR SPEAKER RIGHT SATELLITE SPEAKER RS 485- SUBWOOFER TELEM SIG - TELEM SIG SH W/ MEMORY W/O MEMORY WHT WIRE YEL WIRE

+B AUDIO AMP ANC F- ANC R- AUDIO GND AUDIO L+ AUDIO R- AUDIO SH AUDIO- NAVIGATION UNIT BACK LT- BLK WIRE BLU WIRE BRN WIRE BSM CAM +B BSM CAM GND BSM CAM SH BSM CAM VID BSM SW CAMERA ADPT CAMERA BIT 0 CAMERA BIT 1 CAMERA V GND CAMERA VCC CAMERA VIDEO CTR PRE - CTR SP+ FL PRE- FL SP+ FL TW SP - FR PRE- FR SP+ FR TW SP + FUSE 1 GRN WIRE GRY WIRE GVIF GVIF SH HOT AT ALL TIMES HP L HP R HP R/L GND HP R/L SH LH ROOF SP + LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PNK WIRE PPL PREMIUM RADIO SW REAR SEAT ENTERTAINMENT CIRCUIT RED WIRE RES VID GND RES VID SH RES VID SIG RG GND RG L+ RH ROOF SP + RL PRE- RL SP+ RL SR SP + RR AUX DET RR NTSC RR NTSC GND RR PRE- RR SP- RR SR SP - RS 485- SH CAMERA SUBW PRE- SUBW SP - WHT WIRE YEL WIRE

ACTIVE NOISE CANCELLATION UNIT ANC F- ANC R- BLK WIRE BLU WIRE BRN WIRE CSSAMA CSSAMC DVD PLAYER UNIT FR MIC IN+ FRONT CENTER SPEAKER (+) GA SYS GRN WIRE GRY WIRE INTR LT- LEFT ROOF SPEAKER LT BLU WIRE LT GRN WIRE NCA WIRE NEP ORG/ WIRE PCM (LEFT SIDE OF DASH) PNK WIRE PPL PREMIUM RADIO SW +B REAR ACTIVE NOISE CANCELLATION MICROPHONE REAR CONTROLLER, SCREEN RED WIRE RIGHT ROOF SPEAKER ROOF SPEAKER CONNECTOR RR MIC + RR MIC IN+ VSSOUT W/ RES W/O RES WHT WIRE WHT/BLK WIRE YEL WIRE

+B RADIO BLK WIRE BLU WIRE BRN WIRE CENTER DISPLAY UNIT COMPUTER COMPUTER DATA DATA LINES DRIVER'S MICU DRIVER'S UNDER- DASH FUSE/ RELAY BOX FR MIC IN+ FRONT HFL- NAVIGATION ANC MICROPHONE GA + B GA GND GA SYS ON GA-BUS SH GA-BUS- GRN WIRE GRY WIRE GVIF GVIF SH HANDSFREE- LINK CONTROL UNIT ILLUMI (-) INTERIOR LIGHTS LINES SYSTEM LT BLU WIRE LT GRN WIRE MIC - MIC PWR MIC SH MUTE NCA WIRE ORG/ WIRE PNK WIRE PPL RED WIRE STRWG SW SYSTEM TELEM SIG - TELEM SIG SH USB DATA - USB GND USB SH USB VBUS W/ RES W/O RES WHT WIRE YEL WIRE

+B RADIO AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L GA + B GA AUDIO L- GA AUDIO R- GA GND GA SYS ON GA-BUS SH GA-BUS- GRN WIRE GRY WIRE JOG JOG SH LINES SYSTEM LT BLU WIRE MIC - MIC SH NCA WIRE ORG/ WIRE PPL RED WIRE RF IN RF SH SAT TER SATELLITE SIGNAL ANTENNA XM ANTENNA SH GA AUDIO SH GND TUNE L- TUNE R+ USB DATA - USB GND USB SH USB VBUS VSP W/ RES WHT WIRE XM RECEIVER (IF EQUIPPED) (BASE OF RIGHT "D" PILLAR) YEL WIRE
