Passenger power seat circuit for Honda Odyssey V (2013-2017)
Passenger power seat circuit
BACK- WARD
BLK WIRE
BLU WIRE
BRN WIRE
FOR- WARD
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER SEAT RECLINE MOTOR
FRONT PASSENGER'S POWER SEAT SLIDE MOTOR
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
WHT WIRE
YEL WIRE
