Driver power seat circuit for Honda Odyssey V (2013-2017)
Driver power seat circuit
BACKWARD
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR
DRIVER'S POWER SEAT REAR UP-DOWN MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT SLIDE MOTOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FORWARD/
FUSE 15
FUSE 32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
YEL WIRE
