Rear camera circuit for Honda Odyssey V (2013-2017)

Rear camera circuit

Get access

+B RADIO AUDIO- NAVIGATION UNIT B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE CAMERA ADPT CAMERA BIT 0 CAMERA BIT 1 CAMERA CAMERA BIT 0 SH CAMERA SH CAMERA V GND CAMERA VCC CAMERA VIDEO COMPUTER DATA LINES SYSTEM FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES ORG/ WIRE PNK WIRE REARVIEW CAMERA (RIGHT SIDE OF TAILGATE) RED WIRE SH CAMERA UNDER-HOOD FUSE/RELAY BOX W/ NAVIGATION W/ POWER TAILGATE W/O NAVIGATION W/O POWER TAILGATE WHT WIRE YEL WIRE
