Honda Odyssey V (2013-2017) svcc as Wiring diagram
This page shows the only wiring diagram for the component.svcc as, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram svcc as (1 of 1)
AS DN
AS UP
AUTO
AUTO DOWN
AUTO UP UP
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DOWN
FRONT PASSENGER'S POWER WINDOW MOTOR
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SWITCH
FRONT PASSENGER'S SWITCH LIGHT
FUSE 18
FUSE 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT "C" PILLAR)
LEFT CESS ARTICULATED HARNESS
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LT BLU WIRE
OFF
OFF DOWN
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PLSA AS
PLSB AS
PNK WIRE
PPL
PULSER
RED WIRE
RIGHT CESS ARTICULATED HARNESS
RIGHT END OF DASH)
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW RELAY
RIGHT REAR POWER WINDOW SWITCH
SVCC AS
UART
UP AUTO UP
VMP AS
W/ MEMORY
W/O MEMORY
W/O POWER SLIDING DOORS
YEL WIRE
Go to component -> Power windows circuit (2 of 2) -> SVCC AS
