Honda Odyssey V (2013-2017) relay circuit board relay control module Wiring diagram
This page shows the only wiring diagram for the component.relay circuit board relay control module, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram relay circuit board relay control module (1 of 1)
ACM CONTROL RELAY
ALTERNATOR
AS FB-1 FUSE
AS PSD MTR FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL UNIT)
ELD UNIT
FR BLOWER FUSE
FROM MULTI-FUSE 2 (DIAGRAM 1 OF 10)
FRONT BLOWER MOTOR RELAY RELAY BOX
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 1
FUSE 10
FUSE 11
FUSE 18
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 3
FUSE 31
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HEADLIGHT LOW RELAY
LT BLU WIRE
LT GRN WIRE
MAIN FUSE
MAIN UNDER- HOOD FUSE BOX
MULTI FUSE 1
MULTI FUSE 3
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PPL
RB MAIN FUSE
REAR WINDOW DEFOGGER RELAY UNDER-HOOD FUSE/RELAY BOX
RED WIRE
RELAY CIRCUIT BOARD RELAY CONTROL MODULE
RIGHT POWER SLIDING DOOR CONTROL UNIT
RIGHT REAR POWER WINDOW RELAY
SEAT HEATER RELAY
STEREO AMPLIFIER
TAILLIGHT RELAY
TO RR FB-1 FUSE (DIAGRAM 4 OF 10)
TO UNDER-DASH SUB-RELAY BOX (DIAGRAM 10 OF 10)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
W/ MEMORY W/O MEMORY
W/O REMOTE STARTING SYSTEM W/ REMOTE STARTING SYSTEM
WHT WIRE
WIPER MAIN RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 10) -> RELAY CIRCUIT BOARD RELAY CONTROL MODULE
