Honda Odyssey V (2013-2017) mir act as com Wiring diagram
This page shows the only wiring diagram for the component.mir act as com, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mir act as com (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL UNIT)
DEFOGGER
DEFOGGER SYSTEM
DOOR MULTIPLEX CONTROL UNIT
DOWN
DRIVER'S DOOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 18
FUSE 26
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
INTERNAL SWITCH POSITIONS
LEFT
LEFT POWER MIRROR
LEFT POWER MIRROR ACTUATOR
LEFT/RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
MIR ACT AS COM
MIR ACT AS LR
MIR ACT AS UD
MIR SW AS COM
MIR SW AS LR
MIRROR DIRECTION SELECTED
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
POWER MIRROR SWITCH
POWER TOPS SYSTEM
POWER WINDOW MASTER SWITCH
PPL
PPL PNK WIRE
RED WIRE
RIGHT
RIGHT END OF DASH)
RIGHT LEFT
RIGHT POWER MIRROR
RIGHT POWER MIRROR ACTUATOR
SIDE TURN SIGNAL LIGHT
SWITCH 1
SWITCH 2
SWITCH 3
UART
UP/DOWN MOTOR
VMP AS PG
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> MIR ACT AS COM
