Honda Odyssey V (2013-2017) driver's power tailgate/parking, backup sensor switch Wiring diagram
This page shows the only wiring diagram for the component.driver's power tailgate/parking, backup sensor switch, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's power tailgate/parking, backup sensor switch (1 of 1)
BLU WIRE
COOL BOX CONTROL SWITCH
DRIVER'S JUNCTION BOX 2
DRIVER'S POWER TAILGATE SWITCH
DRIVER'S POWER TAILGATE/PARKING, BACKUP SENSOR SWITCH
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
LEFT B-PILLAR POWER SLIDING DOOR SWITCH
ON IND.
POWER SLIDING DOOR SWITCH
RED WIRE
RES AUXILIARY JACK ASSEMBLY
VSA OFF SWITCH
W/ MEMORY
W/ PARKING, BACKUP SENSOR SYSTEM
W/O MEMORY
W/O PARKING, BACKUP SENSOR SYSTEM
Go to component -> Instrument illumination circuit (4 of 5) -> DRIVER'S POWER TAILGATE/PARKING, BACKUP SENSOR SWITCH
