Honda Odyssey V (2013-2017) ddc/cec gnd Wiring diagram
This page shows the only wiring diagram for the component.ddc/cec gnd, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ddc/cec gnd (1 of 1)
+V PWR
AUDIO REMOTE SWITCH
BLU WIRE
BRN WIRE
CABLE REEL (IN STEERING WHEEL)
CEC
DDC/ CEC GND
DDC/CEC GND
DISPLAY BUTTON
DOWN CHANNEL SWITCH
DOWN VOLUME SWITCH
FRONT HFL- NAVIGATION ANC MICROPHONE
GRY WIRE
HDMI PORT
HFL- NAVIGATION VOICE CONTROL SWITCH
HFT MUTE
HOT PLUG DET
LT BLU WIRE
MIC -
MIC PWR
MIC SH
MODE SWITCH
NCA WIRE
PNK WIRE
REAR CONTROLLER, SCREEN
RED WIRE
SCL
SDA
STEERING WHEEL)
TELM SIG -
TELM SIG SH
TMDS CLOCK -
TMDS CLOCK SH
TMDS DATA 0 -
TMDS DATA 0 SH
TMDS DATA 1 -
TMDS DATA 1 SH
TMDS DATA 2 -
TMDS DATA 2 SH
UP CHANNEL SWITCH
UP VOLUME SWITCH
UTILITY
WHT WIRE
YEL WIRE
Go to component -> Rear seat entertainment circuit, w/ navigation & res wide (3 of 3) -> DDC/CEC GND
